Climate Control: Component Locations Jaguar XJ X351

Automatic HVAC System 3 illustrations

COMPONENT LOCATION

Note. Right-hand drive (RHD) installation shown, left-hand drive (LHD) installation similar.

Item NumberDescription
1Right-hand (RH) ventilation outlet
2Left-hand (LH) ventilation outlet
3Air inlet duct
4Heater assembly

Note. right-hand drive (RHD) 3.0L diesel installation shown, other installations similar.

Scheme 70

Scheme 70: COMPONENT LOCATION
Item NumberDescription
1Evaporator
2Thermostatic expansion valve
3Low pressure line
4Receiver drier
5Condenser
6Air conditioning (A/C) compressor
7Low pressure servicing connection
8High pressure servicing connection
9High pressure line

Component Location RHD Petrol Engine Vehicles (NAS Market From 14 My)

Scheme 71

Scheme 71
ItemDescription
1Evaporator
2Thermostatic expansion valve
3Low pressure line
4Receiver drier
5Condenser
6A/C compressor
7Low pressure servicing connection
8High pressure servicing connection
9High pressure line
10Internal heat exchanger
11Manifold
12Low pressure line
13Low pressure line

Note. left-hand drive (LHD) installation shown, right-hand drive (RHD) installation similar.

Component Location - Sheet 1 Of 2

Scheme 72

Scheme 72: COMPONENT LOCATION
Item NumberDescription
1Pollution sensor (where fitted)
2Front sunload sensor
3Rear sunload sensor (where fitted)
4Ambient air temperature sensor
5Refrigerant pressure sensor

Component Location - Sheet 2 Of 2

Item NumberDescription
1Evaporator temperature sensor
2TSD (touch screen display)
3ICP (integrated control panel)
4Rear climate control panel
5Humidity and temperature sensor
