Electronic Engine Controls (V8 S/c 5.0L Petrol): Removal & Installation Jaguar XFR I

Engine Control Systems 35 illustrations ~1027 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 2

Scheme 2: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm

INSTALLATION

  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 3

Scheme 3: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 4

Scheme 4: REMOVAL

Scheme 5

Scheme 5
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 6

Scheme 6: REMOVAL

Scheme 7

Scheme 7
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 8

Scheme 8: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  3. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Scheme 9

Scheme 9: REMOVAL

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  3. Refer to «Secondary Bulkhead Panel LH»(ref-568406-S25565044692013072200000) information.
  4. Torque: 25 Nm
  5. Torque: 25 Nm
  6. Torque: 8 Nm
  7. Torque: 6 Nm
  8. Torque: 10 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 15

Scheme 15: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Engine Cover - 5.0L, Vehicles With: Supercharger»(ref-568405) information.
  3. Refer to «Cooling System Draining and Vacuum Filling - Vehicles With: Supercharger»(ref-568464) information.
  4. Refer to «Secondary Bulkhead Center Panel»(ref-568406-S23451519502013072200000) information.
  5. Lift the tang and rotate the engine coolant temperature (ECT) sensor counter-clockwise.
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 16

Scheme 16: REMOVAL
  1. Raise and support the vehicle.
  2. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  3. Refer to «Engine Oil Draining and Filling»(ref-568453) information.
  4. Torque: 11 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 17

Scheme 17: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 18

Scheme 18: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 19

Scheme 19: REMOVAL
  1. Refer to «Fuel System Pressure Release - 5.0L»(ref-568404) information.
  2. Disconnect the battery ground cable. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  3. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  4. Refer to «Secondary Bulkhead Panel RH - 5.0L/3.0L Diesel»(ref-568406-S22586568902013072200000) information.
  5. Refer to «Secondary Bulkhead Panel LH - 5.0L/3.0L Diesel»(ref-568406-S25565044692013072200000) information.
  6. Refer to «Engine Cover - 5.0L»(ref-568405-S41842828132013072200000) information.
  7. Torque: 32 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 20

Scheme 20: REMOVAL

Scheme 21

Scheme 21
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Refer to «Catalytic Converter LH»(ref-568457-S11704519152013072200000) information.
  5. Wrench, H02S (310-121) Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 22

Scheme 22: REMOVAL

Scheme 23

Scheme 23
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Air Deflector»(ref-568406-S42840487662013072200000) information.
  4. Refer to «Catalytic Converter RH»(ref-568457-S03385691802013072200000) information.
  5. Wrench, H02S (310-121) Torque: 48 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a long drive cycle. Refer to «Powertrain Control Module (PCM) Long Drive Cycle Self-Test»(ref-568420-S37791637132013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 24

Scheme 24: REMOVAL

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28
  1. Refer to «Engine Cover - 5.0L»(ref-568405-S41842828132013072200000) information.
  2. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
  3. Torque: 10 Nm
  4. Torque: 10 Nm
  5. Torque: 5 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 29

Scheme 29: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 30

Scheme 30: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 31

Scheme 31: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-568400-S03532047432013072200000) information.
  2. Raise and support the vehicle.
  3. Refer to «Supercharger»(ref-568408-S33649561512013072200000) information.
  4. Torque: 20 Nm
  1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 32

Scheme 32: REMOVAL

Scheme 33

Scheme 33
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 34

Scheme 34: REMOVAL

Scheme 35

Scheme 35

Scheme 36

Scheme 36
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-568476) information.
  2. Raise and support the vehicle.
  3. Thermostat Housing Refer to: «Thermostat Housing V8 S/C 5.0L Petrol»(ref-568454-S07823677632013072200000)
  4. Torque: 10 Nm
  1. To install, reverse the removal procedure.
  2. If required, carry out a short drive cycle. Refer to «Powertrain Control Module (PCM) Short Drive Cycle Self-Test»(ref-568420-S05827087332013072200000) information.
