| Description | Nm |
|---|---|
| Accessory drive belt tensioner retaining bolt | 40 |
| Accessory drive belt idler pulley retaining bolt - all vehicles | 40 |
| Accessory drive belt center idler pulley retaining bolt - vehicles without supercharger | 25 |
| Accessory drive belt idler pulley retaining bolt to tensioner bracket - vehicles with supercharger | 40 |
| Supercharger belt tensioner bracket retaining bolt | 25 |
| Supercharger belt tensioner retaining bolt | 40 |
| Supercharger belt 76mm idler pulley retaining bolt | 40 |
| Supercharger belt 90mm idler pulley retaining bolt | 56 |
Scheme 1
| Item Number | Description |
|---|---|
| A | Primary accessory drive |
| B | Secondary accessory drive |
| 1 | Coolant pump |
| 2 | Power steering pump |
| 3 | Primary drive belt |
| 4 | A/C (air conditioning) compressor |
| 5 | Belt tensioner |
| 6 | Crankshaft pulley/torsional vibration damper |
| 7 | Idler pulley |
| 8 | Generator |
| 9 | Idler pulley |
| 10 | Supercharger |
| 11 | Idler pulley |
| 12 | Belt tensioner |
| 13 | Secondary drive belt |
| 14 | Idler pulley |
