Air conditioning — Fuel fired heater circuit Jaguar XF II
All systems — 37 systems
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft 2
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control 2.0l turbo diesel
- Cruise control 3.0l sc
- Defoggers 3
- Electronic power steering 2
- Electronic suspension
- Engine performance 2.0l turbo diesel
- Engine performance 3.0l sc
- Exterior lights 3
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 5
- Navigation 8
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 5
- Power top/sunroof
- Power windows
- Radio 4
- Shift interlock
- Starting/charging 2.0l turbo diesel 2
- Starting/charging 3.0l sc 2
- Supplemental restraints
- Transmission 2.0l turbo diesel 2
- Transmission 3.0l sc 2
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer 3
Components on these wiring diagrams 15
Click a component to highlight it on every diagram it appears on.
