Scheme 1
| Item Number | Description |
|---|---|
| 1 | Door actuator |
| 2 | Safety belt buckle |
| 3 | Instrument cluster |
| 4 | J Gate (Automatic only) |
| 5 | Engine compartment switch - visual warning only |
| 6 | Headlamp switch |
| 7 | Ignition switch |
| 8 | Luggage compartment switch - visual warning only |
| 9 | Generic electronic module (GEM) |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | Door actuator |
| 2 | Safety belt buckle |
| 3 | Instrument cluster |
| 4 | J Gate (Automatic only) |
| 5 | Engine compartment switch - visual warning only |
| 6 | Headlamp switch |
| 7 | Ignition switch |
| 8 | Liftgate switch - visual warning only |
| 9 | Liftgate window glass switch - visual warning only |
| 10 | Generic electronic module (GEM) |
The driver warning chime provides the driver with an audible warning
- when the key is in the ignition and the driver door is open (North American vehicles only).
- when the headlamps are on and the driver door is open with the ignition off.
- when the engine is running and the safety belt is not engaged (driver side only).
The driver will also be provided with a visual warning or visual message displayed in the information message center (if fitted). The system uses a number of inputs to provide the driver with audible and visual warnings.
