Specifications
| Item | Specification |
|---|---|
| Power assisted steering fluid | Dexron 2E |
General Specifications
| Description | Nm |
|---|---|
| Tie rod end retaining nut | 35 |
| Power steering pump retaining bolts | 25 |
| Extension shaft lower retaining bolt | 27 |
| Power steering gear actuator retaining bolts | 3 |
| Power steering gear retaining bolts | 115 |
| Latch plate to pinion housing retaining bolt | 10 |
Torque Specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Fluid cooler |
| 2 | Low pressure pipe - fluid cooler to reservoir |
| 3 | Fluid reservoir |
| 4 | Power steering pump suction hose |
| 5 | Power steering pump |
| 6 | Heat shield |
| 7 | Extension shaft |
| 8 | Dash panel seal |
| 9 | High pressure pipe |
| 10 | Steering gear |
| 11 | Tie-rod end |
| 12 | Low pressure pipe - steering gear to fluid cooler |
Vehicles with 2.0L or diesel engines
The power steering system uses a rack and pinion type, variable ratio steering gear. The power steering pump is belt driven on all model variants and the power steering oil cooler is of a wire bound tube type and is mounted in front of the radiator.
Vehicles with 2.5L or 3.0L engines
The power steering system uses a rack and pinion type, variable ratio steering gear with servotronic steering assistance. The power steering pump is belt driven on all model variants and the power steering oil cooler is of a wire bound tube type and is mounted in front of the radiator.
A variable steering rack ratio reduces the amount of turns from lock to lock to improve parking maneuvers without loosing any steering feel at higher speeds.
The steering assistance decreases smoothly at a calibrated rate to increase the steering efforts required as vehicle speed increases. The steering efforts are controlled by the servotronic valve (actuator) position, which in turn is controlled electronically by the servotronic ECU housed in the instrument cluster.
Absolute cleanliness must be observed when replenishing the fluid or dismantling any part of the system. New fluid from a sealed container must be used.
Note. If the steering gear, pump or cooler are being replaced for leakage or noise related issues and there is no evidence of fluid contamination, there is no need to replace the reservoir.
In some cases where the fluid clearly contains particulate matter, and the system continues to function, flush the system with fresh fluid and replace the reservoir, as there is the possibility that the reservoir internal filter may be damaged or faulty.
For additional information, refer to Steering System - General Information article. .
- For additional information, refer to «Steering System - General Information»(ref-311844) article. .
Scheme 2
Scheme 3
Scheme 4
Scheme 5
- Raise and support the vehicle. For additional information, refer to «Jacking and Lifting»(/jaguar/x-type/i-2008-2009/remont/hoistjack/#jacking-and-lifting) article. .
- Remove the exhaust front muffler. For additional information, refer to «Exhaust System»(ref-311856) article. .
- Remove the heat shield.
- Disconnect the electrical connector.
- Remove the actuator.
- Remove and discard the filter.
