Specifications
| Specification | |
|---|---|
| Bush installation lubrication | Shell gravex oil 973 |
Lubricants, Fluids, Sealers and Adhesives
| Description | Nm |
|---|---|
| Front subframe front mount retaining bolts | 142 |
| Front subframe rear mount retaining bolts | 142 |
| Front subframe reinforcement plate retaining bolts | 35 |
| Front stabilizer bar link arm retaining nuts | 47 |
| Steering gear heat shield retaining bolts | 7 |
| Steering gear to subframe retaining bolts | 133 |
| Steering gear cooling pipe retaining bolts | 7 |
| Engine roll restrictor retaining bolts | 80 |
| Front lower arm ball joint retaining nuts | 83 |
| Rear subframe mounting retaining bolts | 126 |
| Rear shock absorber to wheel knuckle retaining bolts | 130 |
| Wheel knuckle mounting bracket to body retaining bolts | 126 |
| Rear brake caliper retaining bolts | 32 |
Torque Specifications
Scheme 1
The front subframe is bolted to the body and
- Aids in structural support.
- Provides the mounting surface for the steering gear, the front suspension lower arm, the stabilizer bar and the engine roll restrictor support bracket.
Scheme 2
The rear subframe is bolted to the body and
- Aids in structural support.
- Provides the mounting surface for the rear suspension components, the exhaust hanger insulator and the rear drive differential.
