Specifications
| Description | Specification |
|---|
| Jaguar Premium Cooling System Fluid | ESE-M97B44-A |
| Premium Cooling System Flush | EGR-M14P7-A |
| O-Ring Lubricant | ESE-M99B176-A |
| Engine | Capacity |
|---|
| 2.5/3.0L | 8.25L |
Cooling System Refill Capacities
| Description | Nm |
|---|
| Air conditioning condenser retaining bolts | 7 |
| Block heater | 40 |
| Coolant expansion tank retaining bolt | 3 |
| Cooling fan motor control module retaining screws | 2 |
| Cooling fan motor retaining nuts | 6 |
| Engine block drain plug | 40 |
| Radiator drain plug | 1 |
| Radiator support beam retaining bolts | 25 |
| Thermostat housing retaining bolts | 10 |
| Water pump housing retaining bolts | 10 |
| Water pump to water pump housing retaining bolts | 10 |
| Water pump drive pulley retaining bolts | 11 |
| Water pump housing inlet pipe retaining nuts | 9 |
| Water pump housing inlet pipe retaining studs | 12 |
| Water pump housing outlet pipe retaining bolts | 10 |
Scheme 1
Scheme 1: Cooling Module Components
| Item Number | Description |
|---|
| 1 | Cooling fan motor control module |
| 2 | Cooling fan shroud |
| 3 | Cooling fan, R/H |
| 4 | Radiator upper isolator mounting |
| 5 | Radiator side seal |
| 6 | Radiator lower isolator mounting |
| 7 | Radiator lower seal |
| 8 | Radiator support beam |
| 9 | Radiator lower isolator mounting |
| 10 | Radiator side seal |
| 11 | Radiator |
| 12 | Radiator upper isolator mounting |
| 13 | Radiator upper seal |
| 14 | Cooling fan, L/H |
Scheme 2
Scheme 2: Engine Cooling System Components
| Item Number | Description |
|---|
| 1 | Upper coolant hose |
| 2 | Water pump |
| 3 | Coolant expansion tank |
| 4 | Coolant pressure cap |
| 5 | Thermostat |
| 6 | Engine oil cooler |
| 7 | Engine block heater (cold climate market vehicles only) |
| 8 | Engine block drain plug |
| WARNING | Never remove the coolant pressure cap under any circumstances while the engine is operating. Failure to follow this instruction may result in personal injury. To avoid having scalding hot coolant or steam blow out of the cooling system, use extreme care when removing the coolant pressure cap from a hot cooling system. Wait until the engine has cooled, then wrap a thick cloth around the coolant pressure cap and turn it slowly until the pressure begins to release. Step back while the pressure is released from the system. When certain all the pressure has been released (still with a cloth) turn and remove the coolant pressure cap from the coolant expansion tank. Failure to follow these instructions may result in personal injury. |
| WARNING | To avoid the possibility of personal injury, do not operate the engine with the hood open until the fan blades have been examined for cracks and separation. Failure to follow this instruction may result in personal injury. |
| WARNING | Remove fuse 37 from the engine compartment fuse box prior to performing any under hood service in the area of the cooling fans when the engine is hot, since the cooling fan motors could operate if the engine has been switched OFF. Failure to follow this instruction may result in personal injury. |
| CAUTION | The engine cooling system must be maintained with the correct concentration and type of anti-freeze solution to prevent corrosion and frost damage. |
| CAUTION | Never remove the coolant pressure cap under any circumstances while the engine is operating. Failure to follow this instruction may result in damage to the engine. |
The cooling system consists of the following
- Water pump.
- Thermostat.
- Radiator.
- Coolant expansion tank.
- Coolant pressure cap.
- Two electric cooling fans.
- Cooling fan motor control module.
- Engine oil cooler.
