Specifications
| Item | Specification |
|---|---|
| Battery Capacity Vehicles With Petrol Engines | 80 Ah |
| Battery Capacity Vehicles With Diesel Engines | 80 Ah |
| Battery Cold Cranking Vehicles With Petrol Engines | 680 Amps |
| Battery Cold Cranking Vehicles With Diesel Engines | 640 Amps |
General Specifications
| Description | Nm |
|---|---|
| Battery to starter motor solenoid cable retaining nut - vehicles with 2.0L, 2.5L or 3.0L engines | 12 |
| Battery ground cable to body retaining bolt | 25 |
| Battery ground cable to transmission retaining bolt | 25 |
| Battery ground cable to starter motor retaining bolt - vehicles with manual transmission and 2.0L, 2.5L or 3.0L engines | 35 |
| Generator positive cable retaining nut - vehicles with 2.0L diesel engine | 8 |
Torque Specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Battery clamp retaining nut |
| 2 | Battery clamp |
| 3 | Battery cover |
| 4 | Battery |
| 5 | Battery to starter motor solenoid cable |
| 6 | Battery tray |
| 7 | Battery ground cable |
| 8 | Battery clamp retaining bolt |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | Battery to generator and starter motor positive cable |
| 2 | Battery cover |
| 3 | Battery |
| 4 | Battery tray |
| 5 | Battery ground cable |
| 6 | Battery clamp retaining bolt |
| 7 | Battery clamp |
| 8 | Battery clamp retaining nut |
The battery fitted is a 12 volts (DC) 80 ampere hour.
The battery ground cable consists of two heavy duty cables which are connected between the battery ground distributor pole and both the vehicle body and transmission.
Battery - Diagnostic Procedures
For additional information, refer to the battery care manual.
