Steering Column Switches: Diagnosis Jaguar X-type I

Inspection and Verification

1. Verify the customer concern.
2. Visually inspect for obvious signs of electrical damage.

Visual Inspection Chart

Electrical

1. Wiring harness for damage or corrosion
2. Electrical connector(s)
3. Switch(s)
4. Relay(s)
5. Module

1. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
2. If the cause is not visually evident, verify the symptom and refer to the .

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. Remove the driver side instrument panel lower trim panel pocket.
2. Remove the driver side instrument panel lower trim panel.
3. Remove the steering column lower shroud.
4. Remove the steering column upper shroud.
5. Detach the steering column multifunction switch left-hand. Release the retaining tang.
6. Remove the steering column multifunction switch left-hand. Disconnect the electrical connector.
