Contents Wiring diagrams Section: Steering Column All sections

Steering Column: Other Jaguar X-type I

Steering Column 15 illustrations ~249 words

All vehicles

  1. Remove the clockspring. For additional information, refer to CLOCKSPRING ( )

Scheme 6

Scheme 6: Vehicles without Driver Lower Airbag Module
  1. Remove the driver side instrument panel lower trim panel.

Vehicles with Driver Lower Airbag Module

  1. Remove the driver lower airbag module. For additional information, refer to

Scheme 7

Scheme 7: All vehicles

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Disconnect the ignition switch electrical connector. Disconnect the passive anti-theft system transceiver electrical connector. Disconnect the ignition switch electrical connector.
  2. Reposition the steering column wiring harness bracket. Remove the steering column wiring harness bracket retaining screw.
  3. Disconnect the steering wheel rotation sensor electrical connector.
  4. Remove and discard the steering column lower retaining bolt.
  5. Remove the steering column. Remove the steering column retaining bolts. Remove the steering column.

Scheme 12

Scheme 12: Installation

Scheme 13

Scheme 13
  1. To install, reverse the removal procedure.
  2. Tighten in the sequence shown. Tighten to 24 N.m.
  3. Install a new bolt. Tighten to 25 N.m.

Scheme 14

Scheme 14: Removal

Scheme 15

Scheme 15
  1. Remove and discard the steering column lower retaining bolt.
  2. Remove the steering column coupling.

Scheme 16

Scheme 16: Installation

Scheme 17

Scheme 17
  1. To install, reverse the removal procedure. Tighten to 25 N.m.
  2. Install a new bolt. Tighten to 25 N.m.

Scheme 18

Scheme 18: Removal

Scheme 19

Scheme 19
  1. Position the front wheels in a straight ahead position and centralize steering wheel.
  2. Remove the driver airbag module. For additional information, refer to
  3. Disconnect the electrical connector.
  4. Remove the steering wheel.
  5. Using suitable insulation/masking tape, secure the clockspring to prevent movement from the centralized position.

Scheme 20

Scheme 20: Installation
  1. To install, reverse the removal procedure. Tighten to 47 N.m.
