Disc: Specifications — Jaguar X-type I (2001-2009)

Disc: Specifications Jaguar X-type I

TORQUE SPECIFICATIONS

Application		Ft. Lbs. (N.m)
Anchor Plate Bolts
Front		98 (133)
Rear		52 (70)
Brake Booster Retaining Nuts		18 (25)
Brake Master Cylinder Lines		11 (15)
Brake Master Cylinder Retaining Nuts		15 (20)
Caliper Hoses
Front		(1)
Rear (Union Bolt)		28 (38)
Caliper Retaining Bolts
Front		22 (30)
Rear		24 (32)
Driveshaft Center Support Retaining Bolts		18 (25)
Driveshaft Universal Joint Retaining Bolts		32 (44)
Front Muffler Flange Retaining Nuts		41 (55)
Front Muffler Exhaust Hanger Isolation Bracket Bolt		25 (18)
Parking Brake Control Retaining Nuts
Manually Adjusted Parking Brake		18 (25)
Self-Adjusting Parking Brake		15 (20)
Rear Muffler Exhaust Clamp		41 (55)
Wheel Hub Nut		243 (330)
Wheel Lug Nuts (2)
Alloy Wheels		76 (103)
Steel Wheels		59 (80)
Wheel Speed Sensors
Front		(3)
Rear		16 (22)
(1) Tighten to 88 INCH Lbs. (10 N.m). (2) Tighten lug nuts in a diagonal pattern. (3) Tighten to 44 INCH Lbs. (5 N.m).

(1)	Tighten to 88 INCH Lbs. (10 N.m).

(2)	Tighten lug nuts in a diagonal pattern.

(3)	Tighten to 44 INCH Lbs. (5 N.m).

TORQUE SPECIFICATIONS

Application			In. (mm)
Brake Disc
Diameter
Front			11.81 (300)
Rear			11.02 (280)
Discard Thickness
Front			0.87 (22.2)
Rear			0.40 (10.2)
Lateral Runout (All)			0.003 (0.76)
Maximum Thickness Variation (All)			(1) 0.0004 (0.009)
Minimum Refinish Thickness			(2)
Original Thickness
Front			0.94 (24.0)
Rear			0.47 (12.0)
Brake Pad
Minimum Thickness
Front			0.08 (2.0)
Rear			0.08 (2.0)
Original Thickness
Front			0.41 (10.40)
Rear			0.46 (11.8)
Caliper Piston Diameter
Front			2.24 (57.0)
Rear			1.50 (38.0)
Wheel Hub Face Runout (All)			0.002 (0.05)
(1) In 360 degrees. (2) Manufacturer does not provide specification.
