Steering Linkage: Specifications Jaguar X-type I

Manual & Power Steering 2 illustrations ~150 words

Torque Specifications

DescriptionN.m
Tie-rod end retaining nut35
Tie-rod end lock nut40
Wheel nuts - Vehicles with steel wheels80
Wheel nuts - Vehicles with aluminium wheels103

TORQUE SPECIFICATIONS

Scheme 91

Scheme 91: Steering Linkage

The left and right-hand tie-rod assemblies

  1. Transmit steering forces from the steering gear to the wheel hubs.
  2. Provide front road wheel toe setting by adjustment of the threaded outer tie-rod ends.

Note. Steering geometry adjustments must only be carried out with the vehicle on turn plates to allow the wheels to move during adjustment.

The left and right-hand steering rack boots

  1. Are installed between the steering rack and the tie-rod ends.
  2. Are of the concertina type.
  3. Retain lubricant and prevent the ingress of foreign matter.

For additional information, refer toSTEERING SYSTEM-GENERAL INFORMATION .

Scheme 92

Scheme 92: Removal
  1. Remove the tie-rod end. For additional information, refer to procedure in this section: For additional information, refer to ( )
  2. Remove the steering gear boot. Remove and discard the steering gear boot retaining clamp. Detach the steering gear boot retaining clamp. Remove the steering gear boot.
