Uni-Body, Subframe & Mounting System: Overhaul Jaguar X-type I

FRAME ASSEMBLY

The front subframe is bolted to the body and

1. Aids in structural support.
2. Provides the mounting surface for the steering gear, the front suspension lower arm, the stabilizer bar and the engine roll restrictor support bracket.

Scheme 19

The rear subframe is bolted to the body and

1. Aids in structural support.
2. Provides the mounting surface for the rear suspension components, the exhaust hanger insulator and the rear drive differential.

Scheme 20

Scheme 21
