Engine Cooling System - 2.5L/3.0L: Maintenance Jaguar X-type I

Fluids and Lubricants

FLUIDS AND LUBRICANTS SPECIFICATIONS

Cooling System Draining, Filling and Bleeding

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. Remove the coolant expansion tank pressure cap.
2. Remove the undertray. For additional information, refer to FRONT END BODY PANELS .
3. Remove the coolant drain plug. Drain the coolant into a suitable container.
4. Install the drain plug when all coolant has drained. Tighten to 1 N.m. Remove the drain tray.
5. Install the undertray. For additional information, refer to FRONT END BODY PANELS .
6. Lower the vehicle.
7. Remove the engine cover.
8. Fill the cooling system up to the MAX mark on the coolant expansion tank using a 50% mixture of Jaguar Premium Cooling System Fluid or equivalent, meeting Jaguar specification ESE-M97B44-A and 50% distilled water.
9. Install the coolant expansion tank pressure cap.
10. START and RUN the engine at 2000 rpm until the cooling fan operates.
11. Stop the engine and allow to cool for two minutes.
12. Loosely install a pipe clamp to the heater inlet hose.
13. Loosely install a pipe clamp to the heater return hose.
14. START and RUN the engine at 2000 rpm.
15. With the engine at 2000 rpm, fully clamp the heater outlet hose and then fully clamp the heater inlet hose.
16. Continue to run the engine for a further two minutes.
17. Switch the engine off.
18. Remove the heater hose clamps.
19. Fit the engine cover.
20. Allow the vehicle to cool to room temperature.
21. Remove the coolant expansion tank pressure cap, top up the coolant level to the MAX mark on the coolant expansion tank.
22. Install the coolant expansion tank pressure cap.

Cooling System Flushing

Note. To remove rust, sludge and other foreign material from the cooling system, use Premium Cooling System flush, meeting Jaguar specification EGR-M14P7-A, which is safe for use with aluminium cooling systems. This cleaning restores cooling system efficiency and helps prevent overheating.

Note. In severe cases where cleaning solvents will not properly clean the cooling system, it will be necessary to use the pressure flushing method using Cooling System Flusher, 164-R3670 to restore efficient operation.

Note. A pulsating or reversed direction of flushing water will loosen sediment more quickly than a steady flow in the normal coolant flow direction.

Note. Dispose of old coolant and flushing water contaminated with coolant and cleaning chemicals in accordance with local, state and federal laws.

Scheme 108

Scheme 109

1. Remove the air cleaner. For additional information, refer to .
2. Remove the thermostat. For additional information, refer to.
3. Detach the lower coolant hose from the radiator and position to one side.
4. Lower the vehicle.
5. Detach the upper coolant hose from the radiator.
6. Connect a hose pipe to the radiator upper coolant hose connection using a suitable connector.
7. Flush the radiator using the hose pipe until the coolant flowing from the radiator lower coolant hose connection is clear.
8. Remove the hose pipe from the radiator upper coolant hose connection.
9. Connect a hose pipe to the upper coolant hose using a suitable connector.
10. Flush the engine using the hose pipe until the coolant flowing from the radiator lower coolant hose is clear.
11. Remove the hose pipe from the upper coolant hose connection.
12. Connect the upper coolant hose to the radiator.
13. Install the thermostat. For additional information, refer to.
14. Fill the cooling system. For additional information, refer to.
15. Install the undertray. For additional information, refer to FRONT END BODY PANELS .
16. Install the air cleaner. For additional information, refer to .

Scheme 110

Scheme 111

The cooling system consists of the following

1. Water pump.
2. Thermostat.
3. Radiator.
4. Coolant expansion tank.
5. Coolant pressure cap.
6. Two electric cooling fans.
7. Cooling fan motor control module.
8. Engine oil cooler.
