Front Disc Brake: Specifications Jaguar S-type I рестайлинг

Specifications (VIN Range: M45255->N52047)

Note. Brake fluid ITT Super Dot 4 has now been superseded by Shell ESL Super Dot 4 which is the Jaguar recommended brake fluid. Shell ESL Super Dot 4 can be used on all model years.

Lubricants, Fluids, sealers and Adhesives

Torque Specifications

Specifications (VIN Range: N52048->N99999)

Note. Brake fluid ITT Super Dot 4 has now been superseded by Shell ESL Super Dot 4 which is the Jaguar recommended brake fluid. Shell ESL Super Dot 4 can be used on all model years.

Lubricants, Fluids, Sealers and Adhesives

Torque Specifications

Scheme 1

For vehicles without high performance brakes, the brake system consists of the following components

1. Brake pads
2. Double piston, floating calipers
3. Brake discs
4. Brake caliper anchor plates
5. Steel braided brake hoses

The brake caliper has two retaining bolts that attach the brake caliper to the anchor plate. These are of double, sliding piston type which makes sure equal effort is applied through both brake pads. The anchor plate is attached to the wheel knuckle with two bolts. The hydraulic system provides separate circuits for each pair of diagonally opposed wheels (i.e. left front, right rear and right front, left rear).

The brake disc is manufactured from cast iron and is of the vented type. It is retained on the hub by two retaining clips and the wheel studs.

Scheme 2

For vehicles with high performance brakes, the brake system consists of the following components

1. Brake pads
2. Four piston, fixed calipers
3. Drilled brake discs
4. Steel braided brake hoses

The brake caliper has two retaining bolts that attach the brake caliper to the wheel knuckle. These are of four piston fixed type which makes sure that equal effort is applied through both brake pads. The hydraulic system provides separate circuits for each pair of diagonally opposed wheels (i.e. left front, right rear and right front, left rear).

The brake disc is manufactured from cast iron and is of the vented type. It is retained on the hub by two retaining clips and the wheel studs.

Scheme 3

For vehicles with standard brakes, the brake system consists of the following components

1. Brake pads
2. Single piston, floating calipers
3. Brake discs
4. Brake caliper anchor plates
5. Steel braided brake hoses

The brake caliper has two retaining bolts that attach the brake caliper to the anchor plate. These are of single, sliding piston type. The anchor plate is attached to the wheel knuckle with two bolts. The hydraulic system provides separate circuits for each pair of diagonally opposed wheels (i.e. left front, right rear and right front, left rear).

The brake disc is manufactured from cast iron and is of the vented type. It is retained on the hub by two retaining clips and the wheel studs.

Scheme 4

For vehicles with high performance brakes, the brake system consists of the following components

1. Brake pads
2. Single piston, fixed calipers
3. Brake discs
4. Steel braided brake hoses

The brake caliper has two retaining bolts that attach the brake caliper to the anchor plate. These are of single, sliding piston type. The anchor plate is attached to the wheel knuckle with two bolts. The hydraulic system provides separate circuits for each pair of diagonally opposed wheels (i.e. left front, right rear and right front, left rear).

The brake disc is manufactured from cast iron and is of the vented type. It is retained on the hub by two retaining clips and the wheel studs.

For additional information, refer to Brake System - General Information article. .
