Specifications
| Item | Specification |
|---|---|
| Illumination bulb. | 3.0 Watt |
General specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Engine temperature gauge |
| 2 | Left-hand direction indicator |
| 3 | Tachometer |
| 4 | Front fog lamps indicator |
| 5 | High beam indicator |
| 6 | Rear fog lamps indicator |
| 7 | Side lamps indicator |
| 8 | Speedometer |
| 9 | Right-hand direction indicator |
| 10 | Fuel gauge |
| 11 | Safety belt warning indicator |
| 12 | Air bag warning indicator |
| 13 | Anti-lock Brake System (ABS) warning indicator |
| 14 | Parking brake, low brake fluid indicator |
| 15 | Adaptive speed control indicator |
| 16 | Message center red warning indicator-primary warning |
| 17 | Message center display |
| 18 | Message center amber warning indicator-secondary warning |
| 19 | Traction control, Dynamic Stability control (DSC) warning lamp |
| 20 | Check engine warning indicator |
| 21 | Battery charge warning indicator |
| 22 | Engine oil pressure warning indicator |
| 23 | Vehicle overspeed warning indicator |
The instrument cluster provides the driver with information, indicators and warning indicators on the vehicle systems.
The gauges and warning indicators may use the outputs from common sensors to carry out their respective functions.
For European vehicles the anti-lock brake system (ABS) and electric park brake system, the warning indicator is combined, illuminating as an amber exclamation mark.
Instrument cluster bulbs.
There are ten serviceable bulbs fitted to the instrument cluster. Two are indicator bulbs, one fitted each side of the instrument cluster. The remaining bulbs are backlighting bulbs.
Scheme 2
| Item Number | Description |
|---|---|
| 1 | Engine temperature gauge |
| 2 | Left-hand direction indicator |
| 3 | Low exterior temperature warning |
| 4 | Tyre Pressure Monitor System |
| 5 | Tachometer |
| 6 | Pre heat warning light |
| 7 | Check engine warning indicator |
| 8 | Front fog lamps indicator |
| 9 | High beam indicator |
| 10 | Rear fog lamps indicator |
| 11 | Speedometer |
| 12 | Vehicle overspeed warning indicator |
| 13 | Adaptive speed control indicator |
| 14 | Right-hand direction indicator |
| 15 | Fuel gauge |
| 16 | Air bag warning indicator |
| 17 | Safety belt warning indicator |
| 18 | Low fuel warning indicator |
| 19 | Cruise control |
| 20 | ACC / Cruise Control information |
| 21 | Clock |
| 22 | Side lamps indicator |
| 23 | Battery charge warning indicator |
| 24 | Message center red warning indicator-primary warning |
| 25 | Message center |
| 26 | Odometer |
| 27 | Engine oil pressure warning indicator |
| 28 | Message center amber warning indicator-secondary warning |
| 29 | Traction control, Dynamic Stability control (DSC) warning lamp |
| 30 | Anti-lock Brake System (ABS) warning indicator |
| 31 | Engine temperature warning indicator |
| 32 | Parking brake, low brake fluid indicator |
The instrument cluster provides the driver with information, indicators and warning indicators on the vehicle systems.
The gauges and warning indicators may use the outputs from common sensors to carry out their respective functions.
For European vehicles the anti-lock brake system (ABS) and electric park brake system, the warning indicator is combined, illuminating as an amber exclamation mark.
- Verify the customer concern.
- Visually inspect for obvious signs of electrical damage. Visual Inspection Chart Mechanical Electrical Fluid level(s) Accessory installations Bulbs(s) Fuse(s) Wiring harness Electrical connector(s) Engine compartment components Underbody components Instrument cluster
- If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to the next step.
- If the cause is not visually evident, verify the symptom and refer to the Jaguar Approved Diagnostic System.
Scheme 3
Scheme 4
- Remove the instrument cluster. Refer to «Instrument Cluster - Removal and Installation»(ref-311329-S39589586582009032500000) .
- Remove the instrument cluster housing.
- Remove the indicator bulb.
