Specifications
| Description | Nm |
|---|---|
| Front lower arm to front subframe retaining nut and bolt | 175 |
| Rear lower arm to front subframe retaining nut and bolt | 175 |
| Engine mount lower retaining nut | 63 |
| Steering gear retaining bolts | 100 |
| Front Shock absorber and spring assembly retaining bolt | 175 |
| Front subframe to body front retaining bolt | A |
| Front subframe to body rear retaining bolt | A |
| Stabilizer bar link retaining nut | A |
| Stabilizer bar link retaining nut and bolt | 70 |
| Rear Shock absorber and spring assembly retaining bolt | 133 |
| Rear subframe reinforcement plate retaining bolts | 47 |
| Rear subframe to body retaining bolts | 125 |
| A = refer to the procedure for correct torque sequence |
Torque Specifications
Scheme 1
The front subframe is bolted to the body and aids in structural support. The subframe provides the mounting surface for the steering gear, the front suspension lower arms, the stabilizer bar and the engine mounts.
Scheme 2
The rear subframe is bolted to the body and aids in structural support. The subframe provides the mounting surface for the rear suspension components, the exhaust hanger insulators and the rear drive differential.
