Specifications
| Description | Nm |
|---|---|
| Centre bearing retaining bolts | 40 |
| Transmission flexible joint retaining bolts | 108 |
| Rear drive axle flexible joint retaining bolts | 88 |
| Support bracket retaining bolts | 9 |
| Driveshaft heat shield retaining bolts | 7 |
Torque Specifications
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Transmission flexible joint retaining nut |
| 2 | Transmission flexible joint washer |
| 3 | Transmission flexible joint retaining bolt |
| 4 | Centre bearing spacer |
| 5 | Centre bearing spacer |
| 6 | Centre bearing retaining bolts |
| 7 | Rear drive axle flexible joint |
| 8 | Rear drive axle flexible joint retaining bolt |
| 9 | Rear drive axle flexible joint washer |
| 10 | Rear drive axle flexible joint retaining nut |
| 11 | Rear drive axle flexible joint balance nut |
| 12 | Rear driveshaft tube |
| 13 | Collapsible front driveshaft tube |
| 14 | Transmission flexible joint |
| CAUTION | To preserve 'drive line' refinement, individual parts, other than fixings, MUST NOT be renewed. In the event of any balance or driveshaft component related concern, the complete assembly must be renewed. Under no circumstances may the flexible coupling be removed from the driveshaft (or its fixings be loosened). Do not drop or subject the driveshaft to damage. |
Note. All driveshaft assemblies are balanced. If undercoating the vehicle, protect the driveshaft, universal joints and the rear drive axle shafts to prevent over-spray of the undercoating material.
The driveshaft consists of the following
- A two piece welded steel tube with a splined center slip joint.
- A universal joint.
- A center bearing.
- Two flexible joints.
