Specifications
| Engine Specification | Vehicle Specification | ||
|---|---|---|---|
| Europe | Rest of World | ||
| Vehicles fitted without electrical optional extras. | Vehicles fitted with electrical optional extras. | ||
| Vehicles fitted with 2.5L engine | 80 Ah | 90 Ah | 90 Ah |
| Vehicles fitted with 2.7L Diesel engine | 95 Ah | 95 Ah | 95 Ah |
| Vehicles fitted with 3.0L engine | 90 Ah | 90 Ah | 90 Ah |
| Vehicles fitted with 4.2L engine | 90 Ah | 90 Ah | 90 Ah |
Battery Specification
| Item | Specification |
|---|---|
| 95 Ah Battery Cold Cranking | 800 Amps |
| 90 Ah Battery Cold Cranking | 680 Amps |
| 80 Ah Battery Cold Cranking | 640 Amps |
Battery Cold Cranking Specification
| Description | Nm |
|---|---|
| Battery positive cable to rear junction box retaining nut. | 12 |
| Battery positive cable front terminal retaining nut. | 12 |
| Battery ground cable to body retaining bolt. | 12 |
| Battery tray. | 10 |
| Battery cable terminal . | 4 |
Torque Specifications
Scheme 26
| Item Number | Description |
|---|---|
| 1 | Battery negative cable |
| 2 | Battery positive cable |
| 3 | Battery tray |
| 4 | Battery |
The battery fitted is a 12 volts (DC) high cold cranking amperage type.
The battery cables consist of heavy duty negative and positive cables. They are bolted to the battery clamp distributor poles which are of dissimilar size to avoid reverse connection.
Vehicles built from 02/2004
The battery positive cable is routed externally along the right-hand side of the vehicle and is protected by the floor under tray and a jacking shield at the right-hand side rear jacking point.
Care must be taken when jacking and lifting the vehicle on the right-hand side.
Battery - Diagnostic Procedures
For additional information, Refer to Charging System - General Information article.
