A/C Compressor and Clutch Assembly
Note. The internal A/C compressor components are not serviced separately. The A/C scroll compressor is serviced only as an assembly.
The A/C compressor has the following characteristics
- A variable capacity function controlled by a suction pressure device.
- Vehicles fitted with 4.2L engine a displacement of 105cc.
- Vehicles fitted with 2.5L and 3.0L engine a displacement of 90cc.
- A fixed and orbiting scroll to provide refrigerant compression.
- A non-serviceable shaft seal.
Scheme 41
| Item Number | Description |
|---|---|
| 1 | Clutch field coil |
| 2 | Field coil snap ring |
| 3 | Clutch pulley |
| 4 | Pulley snap ring |
| 5 | Clutch hub spacer |
| 6 | Clutch |
| 7 | Clutch nut |
The magnetic A/C clutch has the following characteristics
- It drives the compressor shaft.
- When battery positive voltage is applied to the A/C clutch field coil, the clutch disc and hub assembly is drawn toward the A/C clutch pulley.
- The magnetic force locks the clutch disc and hub assembly and the A/C clutch pulley together as one unit, causing the compressor shaft to rotate.
- When battery positive voltage is removed from the A/C clutch field coil, springs in the clutch disc and hub assembly move the clutch disc away from the A/C clutch pulley.
