Specifications
| Description | Nm | Lb/Ft | Lb/In |
|---|---|---|---|
| Passenger Air Bag Module Retaining Nuts | 12 | 9 | |
| Passenger Air Bag Module Retaining Bolts | 9 | 80 | |
| Restraints Control Module (RCM) Retaining Nuts | 12 | 9 | |
| Seat Position Sensor Retaining Bolt | 5 | 44 | |
| Side Air Curtain Module Inflator Retaining Bolts | 9 | 80 | |
| Side Air Curtain Module Retaining Screws | 1 | 9 | |
| Side Air Curtain Module Tether Straps Retaining bolts | 9 | 80 | |
| Side Air Bag Module Retaining Nuts | 7 | 62 | |
| Side Impact Sensor Retaining Bolt | 12 | 9 | |
| Crash Sensor Retaining bolt | 12 | 9 | |
| Driver Air Bag Module Retaining Screws | 7 | 62 | |
| Clockspring retaining screws | 5 | 44 |
Torque Specifications
The air bag supplemental restraint system (SRS) is designed to provide increased collision protection for vehicle occupants in addition to that provided by the three-point safety belt system. Safety belt use is necessary to obtain the best occupant protection and to receive the full advantages of the SRS.
The air bag supplemental restraint system (SRS) components are shown in the following illustrations.
Scheme 1
| Item Number | Description |
|---|---|
| 1 | Side air curtain module |
| 2 | Side air bag module |
| 3 | C-Pillar side impact sensor |
| 4 | B-Pillar side impact sensor |
| 5 | Seat position sensor |
| 6 | Driver air bag module |
| 7 | Clockspring |
| 8 | Safety Belt pretensioner |
| 9 | Restraints control module (RCM) |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | Rear safety belt retractor and pretensioner |
| 2 | Side air curtain module |
| 3 | Passenger air bag module |
| 4 | Crash sensor |
| 5 | Front passenger seat occupant classification sensor |
| 6 | Front safety belt pretensioner |
| 7 | B-Pillar side impact sensor |
| 8 | C-Pillar side impact sensor |
| 9 | Side air bag module |
