Seating: Diagnosis Jaguar S-type I

Diagnosis and Testing

The complexity of the electronics involved with the seating, of which the DSM is a part, and the multiplexed communication network which are connected to it preclude the use of workshop general electrical test equipment. Therefore, reference should be made to the Jaguar Approved Diagnostic System for detailed instructions on testing the seating.

The Jaguar Approved Diagnostic System systematically tests and analyses all functions and the various systems affected by it.

Where a fault is indicated, some basic diagnostic methods may be necessary to confirm that connections are good and that wiring is not damaged before installing a new component.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Position the seat as rearward as possible to aid removal of the seat.
2. Remove the front bolt and washer.
3. Move the seat as far forward as possible to aid removal of rear nuts.
4. Remove the seat mounting feet trim covers. Detach the front cover from the seat track. (1) Detach the rear cover from the seat track. (2) Remove the trim covers. (3)
5. Remove the rear nuts.
6. Disconnect the battery ground cable.
7. Disconnect the seat electrical connectors. Tilt the seat forward to aid disconnection of the electrical connectors.
8. Remove the seat outer trim panel.
9. Detach the safety belt lower anchor.
10. Remove the seat.

Scheme 9

Scheme 10

Scheme 11

1. To install, reverse the removal procedure.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Remove the front seat. For additional information, refer to «FRONT SEAT»(ref-207820-S21763198772005120100000) .
2. Remove the front seat adjustment switches. For additional information, refer to «SEAT CONTROL SWITCH»(ref-207820-S01932825862005120100000) .
3. Remove the front seat backrest cover. For additional information, refer to «FRONT SEAT BACKREST COVER»(ref-207820-S11982219612005120100000) .
4. Remove the lumbar support motor. For additional information, refer to «LUMBAR MOTOR»(ref-207820-S17227472732005120100000) .
5. Remove the side air bag module. For additional information, refer to «AIR BAG RESTRAINT SYSTEMS»(ref-150745) .
6. Remove the outer seat trim panel.
7. Remove the inner seat trim panel.
8. Disconnect the safety belt buckle electrical connector.
9. Remove the safety belt buckle.
10. Detach the wiring harness. Disconnect the electrical connector. (1) Detach the grommet from the seat backrest. (2)
11. Detach the wiring harness.
12. Remove the seat backrest. Remove the bolts. (1) Remove the seat backrest. (2)

Scheme 19

Scheme 20

1. To install, reverse the removal procedure.

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

1. Remove the front seat. For additional information, refer to «FRONT SEAT»(ref-207820-S21763198772005120100000) .
2. Remove the front seat adjustment switches. For additional information, refer to «SEAT CONTROL SWITCH»(ref-207820-S01932825862005120100000) .
3. Remove the front seat backrest trim panel. The backrest trim panel Is secured by clips. Care must be taken when removing the trim panel.
4. Detach the wiring harness.
5. Disconnect the electrical connectors. Detach the wiring harness. (1) Disconnect the electrical connectors. (2)
6. Detach the front seat backrest cover.
7. Detach the lower section of the seat backrest cover. Remove the clips.
8. Remove the headrest.
9. Remove both headrest guides. Depress the guide. (1) Remove the guide. (2)
10. Remove the air bag module. Disconnect the side air bag module electrical connector. (1) Remove the nuts. (2) Remove the side air bag module. (3)
11. Remove then seat backrest cover and squab.
12. Detach with care the seat backrest cover.
13. Carefully remove the retaining trim rings.
