TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Brake Line-To-Caliper Hose Union Nuts | 16-19 (22-26) |
| Brake Line Union Nuts |
| Female |
| M10 | 9.6-13.0 (13-17) |
| Male |
| M10 | 9.6-13.0 (13-17) |
| M12 | 11-15 (15-20) |
| M18 | 16-21 (22-28) |
| Caliper Carrier Bolts |
| Front | 103 (140) |
| Rear | 40-49 (54-66) |
| Caliper Hose Lock Nut | 11-15 (15-20) |
| Caliper Mounting Bolts (Brembo) | 44 (60) |
| Caliper Union Bolts |
| Front (Brembo) | 16-19 (22-26) |
| Rear (Brembo) | 16-19 (22-26) |
| Rear (Except Brembo) | 22-30 (30-40) |
| Guide Pins | 18-22 (25-30) |
| Lug nuts (1) |
| Alloy Wheels | 65-75 (88-102) |
| Steel Wheels | 50-60 (68-82) |
| INCH Lbs. (N.m) |
| Bleed Nipples |
| Brembo |
| All | 106-142 (12-16) |
| Except Brembo |
| Front | 35-53 (4-6) |
| Rear | 71-97 (8-11) |
| Front Caliper Hose | 88-124 (10-14) |
| (1) Tighten lug nuts in a diagonal pattern. |
| (1) | Tighten lug nuts in a diagonal pattern. |
| Application | In. (mm) |
|---|
| Brake Pad Thickness |
| Minimum |
| Brembo Brakes | 0.08 (2.0) |
| All Others | 0.08 (2.0) |
| Original |
| Brembo Brakes | (1) |
| All Others | (1) |
| Caliper Piston Diameter |
| Brembo Brakes (Twin Piston) | 1.58 (40) & 1.73 (44) |
| All Others | 2.36 (60.0) |
| Disc Diameter |
| Brembo Brakes | 14.0 (355.0) |
| Non-Supercharged |
| All 1999 | 12.0 (305.0) |
| XK Series 2000-2003 | 12.8 (325.0) |
| Supercharged | 12.8 (325.0) |
| Disc Lateral Runout (All) | 0.004 (0.10) |
| Disc Parallelism | (1) |
| Disc Thickness |
| Discard |
| Brembo Brakes | 1.18 (30.0) |
| All Others | 1.02 (26.0) |
| Minimum Refinish | (1) |
| Minimum Wall (Rotor Thickness Either Side Of Vented Area) |
| Brembo Brakes | 0.264 (6.7) |
| Non-Supercharged | 0.244 (6.2) |
| Supercharged | 0.260 (6.6) |
| Original |
| Brembo Brakes | 1.26 (32.0) |
| All Others | 1.10-1.12 (28.0-28.5) |
| (1) Manufacturer does not provide specification. |
| (1) | Manufacturer does not provide specification. |
FRONT DISC BRAKE SPECIFICATIONS
| Application | In. (mm) |
|---|
| Brake Pad Thickness |
| Minimum |
| Brembo Brakes | 0.08 (2.0) |
| All Others | 0.08 (2.0) |
| Original |
| Brembo Brakes | (1) |
| All Others | (1) |
| Parking Brake Shoe |
| Minimum Thickness | 0.08 (2.0) |
| Original Thickness | (1) |
| Caliper Piston Diameter |
| Brembo Brakes (Twin Piston) | 1.10 (28.0) & 1.18 (30.0) |
| All Others | 1.65 (42.0) |
| Disc Diameter |
| Brembo Brakes | 12.99 (330) |
| All Others | 12.00 (305.0) |
| Disc Lateral Runout (Installed) |
| Brembo Brakes | 0.004 (0.10) |
| All Others | 0.006 (0.15) |
| Disc Parallelism | (1) |
| Disc Thickness |
| Original |
| Brembo Brakes | 1.10 (28.0) |
| All Others | 0.77-0.80 (19.5-20.0) |
| Minimum Refinish | (1) |
| Discard |
| Brembo Brakes | 1.02 (26.0) |
| All Others | 0.73 (18.5) |
| Minimum Wall (Rotor Thickness Either Side Of Vented Area) |
| Brembo Brakes | 0.26 (6.7) |
| All Others | 0.19 (4.9) |
| Parking Brake Drum Diameter (Maximum) | 7.13 (181) |
| (1) Manufacturer does not provide specification. |
| (1) | Manufacturer does not provide specification. |
REAR DISC BRAKE SPECIFICATIONS
