General Specifications
| Item | Specification |
|---|---|
| Power assisted steering fluid | WSA-M2C195-A |
GENERAL SPECIFICATIONS
Torque Specifications
| Description | N.m |
|---|---|
| Tie rod end retaining nut | 75 |
| Power steering pump retaining bolts | 25 |
| Lower steering column slider pinch bolt | 35 |
| Lower steering column to steering gear pinch bolt | 35 |
| Power steering pump support tube bracket bolt | 110 |
| Power steering gear retaining bolts | 103 |
| Power steering pump supply tube | 15 |
| Actuator | 30 |
| Steering gear supply and return tubes | 15 |
TORQUE SPECIFICATIONS
| Item | Specification |
|---|---|
| Power assisted steering fluid | ESSO DEXRON 2E |
GENERAL SPECIFICATIONS
| Description | N.m |
|---|---|
| Tie rod end retaining nut | 75 |
| Power steering pump retaining bolts | 25 |
| Lower steering column slider pinch bolt | 35 |
| Lower steering column to steering gear pinch bolt | 35 |
| Power steering gear retaining bolts | 103 |
| Power steering pump supply tube union | 25 |
| Actuator retaining bolts | 3 |
| Steering gear supply and return tubes retaining bracket bolt | 10 |
| Air conditioning compressor retaining bolts | 25 |
| High pressure hose to sump - Vehicles with 3.0L engine | 10 |
TORQUE SPECIFICATIONS
Scheme 1
The Jaguar S-Type uses a rack and pinion type, variable ratio steering gear with Variable Assist Power Steering (VAPS). The power steering pump is belt driven on all model variants and the power steering oil cooler is of a matrix type and is incorporated with the transmission oil cooler.
A variable steering rack ratio reduces the amount of turns from lock to lock to improve parking maneuvers without loosing any steering feel at higher speeds.
The steering assistance decreases smoothly at a calibrated rate to increase the steering efforts required as vehicle speed increases. The steering efforts are controlled by the actuator position, which in turn is controlled electronically by the Variable Assist Power Steering (VAPS) curve which is incorporated within the Generic Electronic Module (GEM).
Absolute cleanliness must be observed when replenishing the fluid or dismantling any part of the system. A new power steering reservoir must be fitted if the steering gear, pump or fluid cooler is to be replaced. New fluid from a sealed container must be used.
