Instrument Panel and Console: Specifications Jaguar S-type I

Gauges & Instrument Panels 11 illustrations ~365 words

Torque Specifications

DescriptionN.m
Instrument panel retaining bolts.20

TORQUE SPECIFICATIONS

The instrument panel assembly houses the main instrument panel, passenger air bag module, glovebox, and air conditioning outlet vents, all of which can be readily removed without disturbing the instrument panel. The instrument panel wiring harness is located behind the instrument panel assembly to facilitate easy installation in vehicle. The instrument panel must be removed from the vehicle to gain access the wiring harness.

The floor console is located between the front seats and, depending upon trim level, consists of the ashtray, cigar lighter and armrest. The optional telephone is incorporated within the center console if the vehicle is equipped with satellite navigation. Alternatively the center section of the console forms a deep stowage box with a secondary cupholder. In both cases the center console utilizes a rear hinged lid which is padded to form a central arm rest. A color-keyed 'J' gate finisher surmounts the veneer top finisher and the 'SPORT' mode and traction control 'ON/OFF' selector switches are situated immediately to the rear of the 'J' gate. Situated in the rear of the center console are further air distribution grills.

Scheme 24

Scheme 24: Removal

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34
  1. Disconnect the battery ground cable. For additional information, refer to «DISCONNECTING/CONNECTING THE BATTERY»(ref-199517-S12643932252005101900000) .
  2. Release the parking brake boot retaining clip.
  3. Detach the floor console upper section. Open the floor console glove compartment.
  4. Disconnect the cigarette lighter electrical connector.
  5. Disconnect the transmission mode, traction control and cellular phone electrical connectors if equipped.
  6. Detach the transmission selector lever boot.
  7. Remove the floor console upper section.
  8. Detach the floor console retaining bracket. Remove the lower floor console retaining bracket retaining screws. (1) Detach the lower floor console retaining bracket. (2)
  9. Remove the floor console glove compartment lid.
  10. Remove the floor console front retaining screws.
  11. Release the floor console rear air register trim panel retaining tangs.
  12. Remove the floor console rear air register trim panel. Release the floor console rear retaining tang. (1) Reposition the floor console side trim panels. (2) Remove the floor console rear air register trim panel. (3)
  13. Remove the floor console.
