Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Disconnect the battery ground cable.
2. Remove the fuel system pressure relief valve cap.
3. Install the special tool to the fuel system pressure relief valve.
4. Relieve the fuel system pressure. Rotate the tap of the special tool fully counterclockwise.
5. Remove the special tool from the fuel system pressure relief valve.
6. Install the fuel system pressure relief valve cap.
7. Connect the battery ground cable.

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. Open the fuel tank filler pipe flap.
2. Disconnect the battery ground cable.
3. Detach the fuel tank filler pipe cap.
4. Remove the rear seat cushion. Refer to «REAR SEAT CUSHION»(ref-207820-S20332508822005120100000) .
5. Detach and reposition the door opening weatherstrip.
6. Remove the scuff plate trim panel.
7. Detach and reposition the floor covering.
8. Detach and reposition the rear seat cushion insulation.
9. Remove the floor aperture cover.
10. Disconnect the fuel pump module electrical connector.
11. Disconnect the fuel lines push connect fittings. For additional information, refer to «QUICK RELEASE COUPLING - PUSH CONNECT»(ref-199547-S10256562222005101900000) .
12. Using the special tool, remove the fuel pump module locking ring.
13. Detach and reposition the upper part of the fuel pump module.
14. Remove the fuel pump module.
15. Remove and discard the fuel pump module O-ring seal.
16. Using the fuel pump module hole in the fuel tank to gain access to the fuel, remove the fuel from the fuel tank using the fuel tank draining equipment. Follow the manufactures operating instructions.
17. Detach and reposition the left-hand rear door opening weatherstrip.
18. Remove the scuff plate trim panel.
19. Detach and reposition the floor covering.
20. Detach and reposition the rear seat cushion insulation.
21. Remove the floor aperture cover.
22. Disconnect the fuel transfer pump electrical connector.
23. Disconnect the fuel lines push connect fittings. For additional information, refer to «QUICK RELEASE COUPLING - PUSH CONNECT»(ref-199547-S10256562222005101900000) .
24. Using the special tool, remove the fuel transfer pump locking ring.
25. Remove the fuel transfer pump.
26. Remove and discard the fuel transfer pump O-ring seal.
27. Using the fuel transfer pump hole in the fuel tank to gain access to the fuel, remove the fuel from the fuel tank using the fuel tank draining equipment. Follow the manufactures operating instructions.
28. Install the fuel transfer pump.
29. Using the special tool, install the fuel transfer pump locking ring. Tighten to 60 N.m.
30. Connect the fuel lines push connect fittings. For additional information, refer to «QUICK RELEASE COUPLING - PUSH CONNECT»(ref-199547-S10256562222005101900000) .
31. Connect the fuel transfer pump electrical connector.
32. Install the floor aperture cover.
33. Attach the rear seat cushion insulation.
34. Attach the floor covering.
35. Install the scuff plate trim panel.
36. Attach the door opening weatherstrip.
37. Install the fuel pump module.
38. Align the upper part of the fuel pump module.
39. Using the special tool, install the fuel pump module locking ring. Tighten to 60 N.m.
40. Connect the fuel lines push connect fittings. For additional information, refer to «QUICK RELEASE COUPLING - PUSH CONNECT»(ref-199547-S10256562222005101900000) .
41. Connect the fuel pump module electrical connector.
42. Install the floor aperture cover.
43. Attach the rear seat cushion insulation.
44. Attach the floor covering.
45. Install the scuff plate trim panel.
46. Attach the door opening weatherstrip.
47. Install the rear seat cushion. Refer to «REAR SEAT CUSHION»(ref-207820-S20332508822005120100000) .
48. Attach the fuel tank filler pipe cap.
49. Connect the battery ground cable.
50. Close the fuel tank filler pipe flap.

Scheme 114

1. Relieve the fuel system pressure. For additional information, refer to «FUEL SYSTEM PRESSURE RELEASE»(ref-199547-S41804741852005101900000)
2. Disconnect the push connect fitting. Press the tangs. Disconnect the push connect fitting.
