Transmission — A/t circuit Jaguar F-type I facelift
All systems — 34 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft
- Body control modules
- Computer data lines 3
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering 2
- Electronic suspension
- Engine performance 3.0l sc
- Engine performance 5.0l sc
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 2
- Memory systems 6
- Navigation 7
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 5
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission 2
- Trunk, tailgate, fuel door 2
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 24
Click a component to highlight it on every diagram it appears on.
