Scheme 1
COOLANT TEMPERATURE GAUGE
Pointer should remain in the center (White) band. If gauge registers at the "H" end, stop vehicle immediately and let engine cool. Check engine coolant level.
OIL PRESSURE GAUGE
Pointer should remain in the White range. If gauge registers too high or too low and will not increase when the engine speed is increased, stop the vehicle immediately, and check the oil level after approximately 5 minutes. If oil level is normal, have lubricating system serviced as soon as possible.
OIL PRESSURE WARNING LIGHT
If light glows during operation, oil level is low or there is low oil pressure. If this occurs, stop the vehicle immediately and check oil level. If oil level is normal, have the lubricating system serviced as soon as possible.
ANTI-LOCK BRAKE SYSTEM WARNING LIGHT
Light is designed to monitor the readiness of the anti-lock or rear anti-lock feature on vehicles equipped with the optional anti-lock brake system. Light will come on briefly as a bulb check when the engine is started. If light does not come on initially, or stays on during vehicle operation, have the system serviced.
UPSHIFT INDICATOR (M/T ONLY)
Upshift indicator ("U/S") light will come on to indicate that you can get better fuel economy by shifting to the next higher gear. Best fuel economy can be achieved by accelerating slowly and shifting to the next higher gear when the "U/S" light comes on.
4WD INDICATOR
Light is illuminated when transfer lever is set in the 4H or 4L position.
CHARGING SYSTEM WARNING LIGHT
Light indicates a problem with the electrical charging system. If light comes on while driving, stop vehicle and check alternator belt. If belt has proper tension and light remains on, have system serviced as soon as possible.
"BRAKE" WARNING LIGHT
If this light comes on while driving, it indicates that either the parking brake is on or the brake fluid level is low. This light may also indicate a critically low vacuum level on diesel-powered vehicles.
"CHECK ENGINE" WARNING LIGHT (GASOLINE ENGINES ONLY)
If light comes on and remains on while driving, it indicates a possible malfunction in the engine emission system. Have the system serviced as soon as possible.
CHECK TRANS OR A/T OIL TEMP WARNING LIGHT
Indicator should illuminate briefly as a bulb check when ignition key is turned to ON position. If light comes on during vehicle operation, automatic transmission fluid temperature is too high. Stop vehicle and put selector lever in Park position. With engine idling, wait until light goes off to continue driving. If light does not go off, have system serviced as soon as possible.
OXYGEN SENSOR INDICATOR (2.6L ENGINE ONLY)
If light comes on and remains on while driving, it indicates that the oxygen sensor is in need of replacement.
FUEL FILTER WARNING LIGHT (DIESEL ENGINES ONLY)
Indicates the need to drain the water separator. If light comes on and remains on while driving, drain the water separator immediately.
