ENGINE IDENTIFICATION
I-Mark engine serial number is stamped on flange near transaxle mounting toward front of vehicle. P'UP and Trooper II engine serial numbers are stamped on right upper center part of cylinder body.
| Application | Code | |
|---|---|---|
| I-Mark (1.5L) | 4XC1-U | |
| P'UP | ||
| 1.9L | G200Z | |
| 2.3L | 4ZD1 | |
| Trooper II (2.3L) | 4ZD1 | |
ENGINE CODES
ENGINE COMPRESSION
Test compression with engine at normal operating temperature, spark plugs removed, throttle valve wide open and engine at cranking speed (300 RPM).
| Application | Specification | ||
|---|---|---|---|
| Compression Ratio | |||
| I-Mark (1.5L) | 9.6:1 | ||
| P'UP | |||
| 1.9L | 8.4:1 | ||
| 2.3L | 8.3:1 | ||
| Trooper II (2.3L) | 8.3:1 | ||
| Compression Pressure | |||
| I-Mark | 178 psi (12.5 kg/cm 2 ) | ||
| P'UP & Trooper II | 171 psi (12 kg/cm 2 ) | ||
| Minimum Compression Pressure | |||
| I-Mark | 125 psi (8.8 kg/cm 2 ) | ||
| P'UP & Trooper II | 120 psi (8.4 kg/cm 2 ) | ||
| Maximum Variation Between Cylinders | |||
| I-Mark | 7 psi (0.6 kg/cm 2 ) | ||
| P'UP & Trooper II | 9 psi (0.6 kg/cm 2 ) | ||
COMPRESSION SPECIFICATIONS
SPARK PLUGS
| Application | NGK No. |
|---|---|
| All Models | BPR6ES-11 |
SPARK PLUG TYPE
| Application | Gap: In. (mm) | Torque: Ft. Lbs. (N.m) |
|---|---|---|
| All Models | .040 (1.05) | 18-25 (24-34) |
SPARK PLUG SPECIFICATIONS
HIGH TENSION RESISTANCE
Carefully remove high tension wire from spark plugs and from distributor cap. Using an ohmmeter, check resistance of wire while gently twisting wire. If resistance is not within specifications, or fluctuates from infinity to any value, replace wire.
| Application | Ohms |
|---|---|
| I-Mark | 4000-13,000 |
| P'UP | 31,500-73,500 per foot |
| Trooper II | 9600-22,600 per foot |
HIGH TENSION WIRE RESISTANCE
VALVE CLEARANCE
Note. Before adjusting valve clearance, ensure rocker arm shaft brackets are properly tightened to 16 ft. lbs. (22 N.m).
- Adjust valves every 15,000 miles with engine cold. Measure valve clearance between rocker arm and valve stem.
- Position No. 1 piston on TDC of compression stroke and adjust valves listed in table. Turn crankshaft one full turn (No. 4 piston on TDC of compression stroke) to adjust remaining valves.
| Piston On TDC | Adjust Intake # | Adjust Exhaust # |
|---|---|---|
| 1 | 1 & 2 | 1 & 3 |
| 4 | 3 & 4 | 2 & 4 |
VALVE ADJUSTMENT SEQUENCE
| Application | In. (mm) |
|---|---|
| Intake (Cold) | .006 (.15) |
| Exhaust (Cold) | .010 (.25) |
VALVE CLEARANCE SPECIFICATIONS
VALVE ARRANGEMENT
- Right Side - All intake.
- Left Side - All exhaust.
DISTRIBUTOR
I-Mark, P'UP & Trooper II are equipped with a Nippondenso electronic distributor.
| Application | In. (mm) |
|---|---|
| All Models | .008-.016 (.2-.4) |
DISTRIBUTOR PICK-UP AIR GAP
Scheme 5
IGNITION TIMING
Ensure engine is at normal operating temperature. Connect timing light to either No. 1 or No. 4 cylinder. Loosen distributor clamping bolts and turn distributor in either direction until timing is within specifications. (Scheme 6)and IGNITION TIMING table.
Scheme 6
| Application | Setting | |
|---|---|---|
| I-Mark | ||
| Man. Trans. | (1) 15 @ 750 | |
| Auto. Trans. | (1) 10 @ 1000 | |
| P'UP | ||
| All Exc. Federal Man. Trans. | 6 @ 900 | |
| Federal Man. Trans. | 6 @ 800 | |
| Trooper II | ||
| Calif. | 6 @ 900 | |
| Federal | 6 @ 800 | |
| (1) With vacuum hose connected. Ignition timing is 3° BTDC with vacuum hose disconnected and plugged. | ||
| (1) | With vacuum hose connected. Ignition timing is 3° BTDC with vacuum hose disconnected and plugged. |
IGNITION TIMING (DEGREES BTDC @ RPM)
IDLE SPEED
- Before adjusting idling speed and mixture, check engine timing. If ignition timing is off, adjust to proper value before adjusting idling speed and mixture.
- Set parking brake and block drive wheels. Place transmission in "NEUTRAL" or "PARK" position. Make idling speed adjustment with engine at normal operating temperature. Install air cleaner and open choke valve.
- Turn off air conditioning, (if equipped). If equipped with power steering, front wheels should be facing straight ahead. Turn off all accessories and wait until engine cooling fan stops rotating.
- Disconnect distributor vacuum line from carburetor, canister purge line, EGR vacuum line and Inlet Temperature Control valve (ITC) vacuum line. Adjust throttle adjusting screw to 750 RPM (manual transaxle) and 1000 RPM (automatic transaxle).
- If equipped with air conditioning, turn air conditioner on and set temperature control lever to "MAX COLD" position. Set blower to highest position. Use FICD adjusting screw at tip of carburetor throttle lever to set correct fast idle speed.
- Set manual transaxle vehicles to 850 RPM and automatic transaxle vehicles to 980 RPM. To complete adjustment, see «IDLE MIXTURE»(/isuzu/trooper/i-1981-1991/remont/adjustments/#tune-up-4-cyl__idle-mixture) .
| Application | Idle RPM | |
|---|---|---|
| I-Mark | ||
| Auto. Trans. | 1000 | |
| Man. Trans. | 750 | |
| P'UP | ||
| All Except Federal Man. Trans. | 900 | |
| Federal Man. Trans. | 800 | |
| Trooper II | ||
| Calif. | 900 | |
| Federal | 800 | |
IDLE SPEED SPECIFICATIONS
IDLE MIXTURE
Note. Mixture adjustment is NOT a part of a normal tune-up procedure and should not be performed unless carburetor is overhauled, fuel injection system components are replaced, or vehicle fails emissions testing.
I-Mark, Calif. P'UP & Trooper II Models
- Set parking brake and block drive wheels. Place transmission in "NEUTRAL" or "PARK" position. Remove carburetor from vehicle.
- Drill a hole in seal plug and remove. (Scheme 7) Remove shavings with compressed air. Install carburetor.
- On all models, disconnect and plug distributor vacuum hose, canister purge line and EGR vacuum line. Disable idle compensator vacuum line by pinching rubber hose. With engine at normal operating temperature, choke open and A/C off (if equipped), adjust idle speed.
- Connect positive lead of dwell meter or duty meter to duty monitor. Ground negative terminal. Turn idle mixture screw in all the way. Back out 1 1/2 turns.
- Adjust throttle adjusting screw to specified RPM. See «IDLE SPEED SPECIFICATION»(/isuzu/trooper/i-1981-1991/remont/adjustments/#tune-up-4-cyl) table in this article. Check meter and ensure that dwell is varying. Adjust setting of idle mixture screw to obtain an average dwell or duty as specified.
- Reset throttle adjusting screw. Put idle mixture screw plug back in place. If equipped with A/C, follow steps 3) and 4) of «IDLE SPEED»(/isuzu/trooper/i-1981-1991/remont/adjustments/#tune-up-4-cyl__idle-speed) under ADJUSTMENTS.
Scheme 7
| Application | Setting |
|---|---|
| Dwell Meter | 36° |
| Duty Meter | 40% |
DWELL OR DUTY METER SETTING
Federal P'UP & Trooper II Models
- Set parking brake and block drive wheels. Place transmission in Neutral. Remove carburetor from vehicle. Drill a hole in plug and remove. (Scheme 7) Remove shavings with compressed air. Install carburetor.
- Disconnect and plug distributor vacuum hose, canister purge line and EGR vacuum line. Disable idle compensator vacuum line by bending rubber hose. With engine at normal operating temperature, choke open and A/C off (if equipped).
- Adjust idle speed screw to 750-850 RPM on man. trans. or 850-950 RPM on auto. trans. Turn idle mixture screw in all the way and back out 3 turns. Adjust throttle screw to 800 RPM on man. trans. and 900 RPM on auto. trans.
- Adjust idle mixture screw to achieve maximum speed. Reset idle speed screw to 850 RPM on man. trans. and 950 RPM on auto. trans.
- Turn idle mixture screw clockwise (lean) until engine speed is down to 750-850 RPM on man. trans. and 850-950 RPM on auto. trans. Replace idle mixture screw plug. If equipped with A/C, follow steps 3) and 4) of «IDLE SPEED»(/isuzu/trooper/i-1981-1991/remont/adjustments/#tune-up-4-cyl__idle-speed) under ADJUSTMENT.
COLD (FAST) IDLE SPEED
- Fast idle speed is determined by opening angle of throttle valve on carburetor. It is not set by adjusting engine speed.
- Remove carburetor from engine. Turn throttle stop screw in all the way before measuring clearance. Adjust throttle valve opening with fast idle screw on first step of fast idle cam.
- Close choke valve completely and measure primary throttle valve opening angle. Adjust opening angle with fast idle adjusting screw. Install carburetor.
- With engine at normal operating temperature, distributor, idle compensator and EGR valve vacuum hoses disconnected and plugged, fast idle speed should be about 3200 RPM.
| Application | Throttle Valve Opening Angle |
|---|---|
| Man. Trans. | 15-17° |
| Auto. Trans. | 17-19° |
FAST IDLE SPEED SPECIFICATIONS
HIGH ALTITUDE ADJUSTMENT
Federal vehicles, not originally designed for high altitude applications, can be adjusted to operate at high altitudes by performing the following procedure
- Engine timing should be advanced up to 4 degrees from the recommended setting. However, timing should not be advanced if spark knock occurs at high altitude.
- Engine speeds should be adjusted to the specification shown on the emission control decal.
AUTOMATIC CHOKE
Automatic choke setting is preset at factory and is non-adjustable.
EMISSION CONTROL
See EMISSIONS section.
I-Mark, P'UP and Trooper II models are equipped with a Nippondenso electronic distributor.
| Application | Ohms |
|---|---|
| I-Mark, P'UP & Trooper II | 140-180 |
DISTRIBUTOR PICK-UP COIL RESISTANCE
| Application | Primary | Secondary |
|---|---|---|
| I-Mark | 1.1-1.4 | 12,100-14,900 |
| P'UP & Trooper II | 1.1-1.4 | 8,600-13,000 |
IGNITION COIL RESISTANCE - OHMS @ 68°F (20°C)
FUEL SYSTEM
| Application | Model |
|---|---|
| I-Mark | Stromberg DFP 340 2-Bbl |
| P'UP (Fed.) | Stromberg DCH 340 2-Bbl |
| P'UP (Calif.) | Stromberg DFP 340 2-Bbl |
| Trooper II (Fed.) | Stromberg DCH 340 2-Bbl |
| Trooper II (Calif.) | Stromberg DHP 340 2-Bbl |
CARBURETOR SPECIFICATIONS
| Application | Pressure: psi (kg/cm 2 ) |
|---|---|
| I-Mark, P'UP & Trooper II | 3.56 (.25) |
FUEL PUMP PERFORMANCE
BATTERY
| Application | Amp Hr. Rating |
|---|---|
| All Models | 50 |
BATTERY SPECIFICATIONS
STARTER
All models are equipped with Hitachi starters.
| Application | Volts | Amps | Test RPM |
|---|---|---|---|
| All Models | 11.5 | 60 | 6000 |
STARTER SPECIFICATIONS
ALTERNATOR
All models use Hitachi alternators.
| Application | Rated Amp Output |
|---|---|
| I-Mark, P'UP & Trooper II | 50 |
ALTERNATOR SPECIFICATIONS
ALTERNATOR REGULATOR
All models use Hitachi alternator regulators.
| Application | Voltage |
|---|---|
| I-Mark, P'UP & Trooper II | 13.8-14.8 |
REGULATOR OPERATING VOLTAGE @ 68°F (20°C)
SERVICE INTERVALS
| Component | Interval (Miles) |
|---|---|
| Air Filter | 30,000 |
| Fuel Filter | 30,000 |
| Oil Filter | 15,000 |
| Oxygen Sensor | 30,000 |
| Spark Plugs | 30,000 |
REPLACEMENT INTERVALS
BELT ADJUSTMENT
| Application | (1) Deflection: In. (mm) |
|---|---|
| All Belts | 3/8 (10) |
| (1) Moderate hand pressure applied midway between pulleys on longest belt run. | |
| (1) | Moderate hand pressure applied midway between pulleys on longest belt run. |
BELT ADJUSTMENT
CAPACITIES
| Application | Quantity | ||
|---|---|---|---|
| Crankcase (Includes Filter) | |||
| I-Mark & Trooper II | 3.4 qts. (3.2L) | ||
| P'UP | 3.3 qts. (3.1L) | ||
| Cooling System | |||
| I-Mark | 5.7 qts. (5.4L) | ||
| P'UP | |||
| Man. Trans. | 8.5 qts. (8.0L) | ||
| Auto. Trans. | 8.2 qts. (7.8L) | ||
| Trooper II | 8.5 qts. (8.0L) | ||
| Auto Transaxle (Dexron II) - I-Mark | 6.1 (5.8) | ||
| Auto. Trans. (Dexron II) - P'UP | 6.4 qts. (6.0L) | ||
| Man. Transaxle - I-Mark | 5.9 (2.8) | ||
| Man. Trans. (SAE 30) | |||
| 4-Speed - P'UP | 2.7 pts. (1.3L) | ||
| 5-Speed | 3.3 pts. (1.6L) | ||
| Rear Axle (SAE 90) - P'UP & Trooper II | 2.7 pts. (1.3L) | ||
| Front Axle (SAE 90) | |||
| P'UP | 1.7 pts. (0.8L) | ||
| Trooper II | 2.1 pts. (1.0L) | ||
| Transfer Case (SAE 30) | |||
| P'UP | 5.2 pts. (2.5L) | ||
| Trooper II | 5.2 pts. (2.5L) | ||
| Fuel Tank | |||
| I-Mark | 13.7 gals. (52.0L) | ||
| P'UP | |||
| Long Bed | 19.1 gals. (72.4L) | ||
| All Others | 13.2 gals. (50.0L) | ||
| Trooper II | 21.9 gals. (87.6L) | ||
FLUID CAPACITIES
