Wiring diagram: Radio — Radio circuits, with amplifier Isuzu Rodeo II
All systems — 35 systems
- Air conditioning 2.2l 3
- Air conditioning 3.2l 2
- Anti-lock brakes
- Anti-theft
- Body computer
- Computer data lines 2.2l
- Computer data lines 3.2l
- Cooling fan 2.2l 2
- Cooling fan 3.2l
- Cruise control
- Defoggers
- Electronic suspension
- Engine performance 2.2l
- Engine performance 3.2l
- Exterior lights 2
- Ground distribution
- Headlights
- Horn
- Instrument cluster
- Interior lights 2
- Power distribution
- Power door locks 2
- Power mirrors
- Power seats
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlocks
- Starting/charging 2.2l 2
- Starting/charging 3.2l 2
- Supplemental restraints
- Transmission 2.2l
- Transmission 3.2l 2
- Warning systems
- Wiper/washer 2
Components on these wiring diagrams 17
Click a component to highlight it on every diagram it appears on.
