STARTER SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Carbon Brush | ||
| New Length | .63" (16 mm) | |
| Minimum Length | .43" (11.0 mm) | |
| Commutator | ||
| Diameter | 1.26-1.30" (32-33 mm) | |
| Runout | .004" (0.1 mm) | |
| Armature | ||
| Core Runout | .004" (0.1 mm) | |
| Bench Testing (No Load) | ||
| Minimum Volts | 11.5 | |
| Maximum Amps | 90 | |
| Minimum RPM | 3000 | |
STARTER SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Starter-To-Engine Block Bolt | 30 (40) | |
| Exhaust | ||
| Stud Nuts | 49 (67) | |
| Nuts | 32 (43) | |
| INCH Lbs. (N.m) | ||
| Starter Brush Plate Bolts | 16 (1.9) | |
| Starter Terminals "B" & "S" | 80 (9) | |
| Starter Through-Bolts | 48 (5.6) | |
| Starter-To-Solenoid Bolts | 41 (4.7) | |
TORQUE SPECIFICATIONS
