Maintenance Information: Overview Isuzu Rodeo I

Fuse & Circuit Breaker Identification

1. 1 - 10 Amp Taillights & Side Marker Lights, Parking & License Lights, Instrument Illumination
2. 2 - 10 Amp Stoplight, ECT Computer (4WD A/T)
3. 3 - 10 Amp Interior Lights, Cargo Light, Seat Belt Reminder (Buzzer), ECM Controller (2.6L Engine)
4. 4 - 20 Amp (1991) 25 Amp (1992-94) Rear Defogger, Power Door Locks, Tailgate Glass Release
5. 5 - 10 Amp (1991 2.6L) (1991-92 3.1L) Automatic Transmission Control Module (TCM), Back-up Lights
6. 5 - 10 Amp (1993-94) (3.2L) Automatic Transmission Control Module (TCM), Back-up Lights
7. 5 - 20 Amp (2.6L) (1992-94) Fuel Pump, Fuel Injection System
8. 6 - 15 Amp Windshield Washer & Wiper, Mirror Defoggers
9. 7 - 10 Amp (3.1L & 3.2L) Indicators, Gauges, Turn Signal Lights, Power Windows, Vehicle Speed Sensor (VSS)
10. 7 - 10 Amp (2.6L) Indicators, Gauges, Turn Signal Lights, Rear Window Defogger
11. 8 - 10 Amp (3.1L & 3.2L) Charging System, Back-Up Lights, Fuel Injection System Cruise Control, Brake Lights
12. 8 - 10 Amp (2.6L) Charging System, Back-Up Lights, Fuel Injection System
13. 9 - 15 Amp Ignition Coil
14. 10 - 10 Amp Rear Wiper/Washer
15. 11 - 20 Amp (1991 2.6L) Fuel Pump, Fuel Injection System
16. 11 - 10 Amp (3.1 & 3.2L) (1992-94) Starting System
17. 11 - 10 Amp (2.6L) (1992-94) Starter, Engine Control Module (ECM)
18. 12 - 10 Amp (1991) Starter, Engine Control Module (ECM)
19. 12 - 15 Amp (1992-94) Cigarette Lighter, Radio, Power Mirrors
20. 13 - 15 Amp (1991) Cigarette Lighter, Radio, Power Mirrors
21. 13 - 20 Amp (1992-94) Rear Wheel Anti-Lock Control
22. 14 - 20 Amp (1991) Rear Wheel Anti-Lock Control
23. 14 - 25 Amp (Spare) (1992-94)
24. 15 - 10 Amp (Spare)
25. 16 - 15 Amp (Spare)
26. 17 - 20 Amp (Spare)
27. 18 - 30 Amp (Circuit Breaker) Power Window

Scheme 1

Fusible Link Identification

1. A - 80 Amp (1991-92 3.1L)
2. A - 60 Amp Main-1
3. B - 30 Amp Main-2
4. C - 30 Amp (1993-94) ECM (3.2L)
5. D - 30 Amp Condenser Fan (A/T Models)

Relay Identification

1. 1 - Headlight Relay
2. 2 - A/C - Heater Relay
3. 3 - Starter Relay
4. 4 - A/C Compressor Relay
5. 5 - Charge Relay
6. 6 - Fuel Pump Relay
7. 7 - ECM Relay
8. 8 - Wiper Relay

1. 1 - 15 Amp (1991) ECM, Fuel Injection System
2. 1 - 15 Amp (1992-94 2.6L) ECM, Fuel Injection System
3. 1 - 10 Amp (1992-94 3.1 & 3.2L) Heated Oxygen Sensor, Fuel Injection System
4. 2 - 20 Amp (1991-92) Fuel Pump
5. 2 - 20 Amp (1993-94 2.6L) Fuel Pump
6. 2 - 15 Amp (1993-94 3.2L) Fuel Pump
7. 3 - 10 Amp (1991)
8. 3 - 15 Amp (1992-94) Turn Signal Lights, Hazard Warning Flasher Lights
9. 4 - 10 Amp Horn, Door Locks
10. 5 - Not Used (1991 3.1L)
11. 5 - 10 Amp Charging System, Charge Warning Light
12. 6 - Not Used (1991) (1992-93 2.6L)
13. 6 - 10 Amp (1992-94 3.1L & 3.2L) A/T Interlock System
14. 6 - 10 Amp (1994 2.6L) Heated Oxygen Sensor, Fuel Injection System
15. 7 - 20 Amp Heater/Air Conditioning Blower Controls
16. 8 - 10 Amp Air Conditioner Compressor Controls
17. 9 - 10 Amp Right Headlight
18. 10 - 10 Amp Left Headlight

Scheme 2

Scheme 3

1. 1 - 10 Amp Starter
2. 2 - 20 Amp Fuel Pump
3. 3 - 15 Amp Generator, ECM, VSV EGR (3.2L), VSV Canister (3.2L), Shift Indicator Controller (3.2L)
4. 4 - 15 Amp Ignition Coil (2.6L), Electronic Ignition (3.2L), Power SW (2.6L)
5. 5 - 15 Amp Taillight, Illumination Light, Illumination Controller
6. 6 - Not Used
7. 7 - 15 Amp Meter, Rear Window Defroster Relay, Vehicle Speed Sensor, Seat Belt - Key & Light Reminder Buzzer, Cruise Indicator, Shift Lock Controller
8. 8 - Not Used
9. 9 - 10 Amp Luggage Room Light, Courtesy Light, Dome Light, Map Light, Seat Belt - Key & Light Reminder Buzzer, Audio
10. 10 - Not Used
11. 11 - 20 Amp Front Wiper/Washer, Intermittent Wipers
12. 12 - 10 Amp Cruise Control Unit
13. 13 - 15 Amp Stoplights, High Mounted Stop Light, Cruise Control Unit, Rear Wheel ABS Controller, Automatic Transmission TCM (3.2L), Shift Lock and Shift Indicator Controller (3.2L)
14. 14 - 20 Amp Doorlocks
15. 15 - 15 Amp Back-up, Turn Signal, Flasher, Cruise Control Unit (A/T) Power Window Relay, Mirror Heater
16. 16 - 10 Amp Rear Wiper/Washer
17. 17 - 15 Amp Rear Window Defroster, Hatch Gate Actuator, Defroster Switch
18. 18 - 15 Amp Rear Window Defroster, Hatch Gate Actuator, Defroster Switch
19. 19 - 15 Amp Audio, Power Mirrors
20. 20 - 15 Amp Cigar Lighter
21. 21 - 10 Amp SRS 1 (Airbag) - Warning Light
22. 22 - 10 Amp SRS 2 (Airbag) - Inflator (Driver & Passenger)
23. 23 - 20 Amp Rear ABS Controller
24. 24 - Not Used
25. 25 - Diode Dome Light
26. 26 - Diode Courtesy Light
27. 27 - 30 Amp (Circuit Breaker) Power Window
28. 28 - Spare
29. 29 - Spare
30. 30 - Spare

1. A - Rear Wiper Relay (3.2L)
2. B - Rear Window Defroster Relay
3. C - Tail Lamp Relay
4. D - Power Window Relay
5. E - Upshift Relay

Scheme 4

1. A - Headlight Relay
2. B - A/C - Compressor Relay (3.2L)
3. C - Charge Relay
4. D - Horn Relay
5. E - Thermo Relay
6. F - Starter Relay
7. G - Heater Relay
8. H - ECM Main Relay
9. I - Fuel Pump Relay
10. J - Air Conditioner Fan Relay (3.2L)

1. 1 - 15 Amp (2.6L) Hazard
2. 2 - 10 Amp Horn
3. 3 - Not Used
4. 4 - 20 Amp Blower Motor
5. 5 - 10 Amp Air Conditioner Compressor Clutch, A/C Compressor (3.2L) Fast Idle Control Device (2.6L)
6. 6 - 10 Amp Charge Warning Light
7. 7 - Not Used
8. 8 - 10 Amp Headlamp - LH, High Beam Indicator Lamp
9. 9 - 10 Amp Headlamp - RH
10. 10 - 10 Amp O2 Sensor (Oxygen Sensor)
11. 11 - 20 Amp Fuel Pump 1
12. 12 - 15 Amp ECM, Fuel Injector, VSV, EGR (2.6L), VSV Canister (2.6L), EGR Duty Solenoid (2.6L), VSV Power Regulator (2.6L)
13. 13 - Not Used
14. 14 - 20 Amp Fuel Pump 2 (2.6L)
15. 15 - 100 Amp Main
16. 16 - 60 Amp Key Switch
17. 17 - 30 Amp Condenser Fan
18. 18 - Not Used
19. 19 - Not Used
20. 20 - Diode Starter Relay, Charge Warning Light, Hatch Gate
21. 21 - Diode ECM Relay
22. 22 - Diode Fuel Pump Relay
