Jacking & Hoisting Isuzu Impulse II

Wheel Alignment 2 illustrations ~201 words

Note. Illustrations DO NOT represent exact structure of vehicle frame, underbody, or body outline. Illustrations are given to provide reference point only.

FLOOR JACK

Using a floor jack or hoist, lift vehicle at points indicated by shaded areas on frame. (Схема №1)or (Схема №2).

Fig. 1: Jacking & Hoisting Points (Amigo, Pickup, Rodeo & Trooper) Courtesy of Isuzu Motor Co.
Scheme 1: Jacking & Hoisting Points (Amigo, Pickup, Rodeo & Trooper) Courtesy of Isuzu Motor Co.
Fig. 2: Identifying Jacking & Hoisting Points (Impulse & Stylus) Courtesy of Isuzu Motor Co.
Scheme 2: Identifying Jacking & Hoisting Points (Impulse & Stylus) Courtesy of Isuzu Motor Co.

Amigo & Rodeo

When changing front tire, position jack under front crossmember. Position jack under rear axle housing, near wheel, when changing rear tire.

Impulse & Stylus

When changing front tire, position jack under reinforced point on sill, 4.3" (110 mm) behind front wheel opening. Position jack under reinforced point on sill, 13.4" (340 mm) forward of rear wheel opening.

2WD Pickup

When changing front tire, position jack under cab mounting center bracket. Position jack under rear axle housing, near wheel, when changing rear tire.

4WD Pickup

When changing front tire, position jack under transmission crossmember. Position jack under rear axle housing, near wheel, when changing rear tire.

Trooper

When changing front tire on all but 2.6L with A/T, position jack under front crossmember. Position jack under jacking bracket on 2.6L with A/T. Position jack under rear axle housing, near wheel, when changing rear tire.

See FLOOR JACK .
