Wheel Alignment Specifications & Procedures Isuzu Impulse I

Wheel Alignment 3 illustrations

Caster adjustment. to adjust caster, lengthen or shorten strut rod as shown. Scheme 1

Scheme 1: Caster adjustment. to adjust caster, lengthen or shorten strut rod as shown.
Scheme 1: Caster adjustment. to adjust caster, lengthen or shorten strut rod as shown.

Camber adjustment. Rotate pivot shaft or add shims to adjust camber angle. Scheme 2

Scheme 2: Camber adjustment. Rotate pivot shaft or add shims to adjust camber angle.
Scheme 2: Camber adjustment. Rotate pivot shaft or add shims to adjust camber angle.

Camber & Caster adjustments. To increase/decrease caster angle, move shims from one side to the other. To adjust camber, change shims equally from side to side. Scheme 3

Scheme 3: Camber & Caster adjustments. To increase/decrease caster angle, move shims from one side to the other. To adjust camber, change shims equally from side to side.
Scheme 3: Camber & Caster adjustments. To increase/decrease caster angle, move shims from one side to the other. To adjust camber, change shims equally from side to side.
ApplicationSpecification
Front
Camber in Degrees
Fraction5/16 +/- 1
Decimal.313 +/- 1.0
Caster in Degrees
Fraction2 1/4 +/- 1/2
Decimal2.25 +/- .5
Toe-In in Inches
Fraction0 +/- 1/16
Decimal0 +/- .06
Toe-In in Degrees
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-Out in Turns
Inner(1)
Outer(1)
Steering Axis Inclination (SAI)12 1/8°
Rear
Camber in Degrees
Fraction0
Decimal0
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
Fraction1/16
Decimal.06
Toe-In in Degrees
Fraction1/8
Decimal.13
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (I-MARK)

ApplicationSpecification
Front
Camber in Degrees
Fraction1/4 +/- 3/4
Decimal.25 +/- .75
Caster in Degrees
Fraction2 1/2 +/- 1 1/2
Decimal2.5 +/- 1.5
Toe-In in Inches
Fraction0 +/- 1/13
Decimal0 +/- .06
Toe-In in Degrees
Fraction0 +/- 1/8
Decimal0 +/- .13
Toe-Out in Turns
Inner(1)
Outer(1)
Steering Axis Inclination (SAI)(1)
Rear
Camber in Degrees
Fraction0
Decimal0
Caster in Degrees
FractionN/A
DecimalN/A
Toe-In in Inches
Fraction1/16
Decimal.06
Toe-In in Degrees
Fraction1/8
Decimal.13
Toe-Out in Turns
InnerN/A
OuterN/A
Steering Axis Inclination (SAI)N/A
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (IMPULSE)

ApplicationSpecification
Front ( (Scheme 1)& (Scheme 2) )
Camber in Degrees
Fraction1/2 +/- 1/2
Decimal.5 +/- .5
Caster in Degrees
Fraction1/2 +/- 1/2
Decimal.5 +/- .5
Toe-In in Inches
Fraction3/32 +/- 3/32
Decimal.09 +/- .09
Toe-In in Degrees
Fraction3/16 +/- 3/16
Decimal.19 +/- .19
Toe-Out in Turns
Inner(1)
Outer(1)
Steering Axis Inclination (SAI)7 1/2°
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (P'UP - 2WD)

ApplicationSpecification
Front (Scheme 3)
Camber in Degrees
Fraction9/16 +/- 1/2
Decimal.563 +/- .5
Caster in Degrees
Fraction5/16 +/- 1/2
Decimal.313 +/- .5
Toe-In in Inches
Fraction0 +/- 3/32
Decimal0 +/- .09
Toe-In in Degrees
Fraction0 +/- 3/16
Decimal0 +/- .19
Toe-Out in Turns
Inner(1)
Outer(1)
Steering Axis Inclination (SAI)7 1/16°
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (PU'P - 4WD)

ApplicationSpecification
Front (Scheme 3)
Camber in Degrees
Fraction9/16 +/- 1/2
Decimal.563 +/- .5
Caster in Degrees
Fraction1/2 +/- 1/2
Decimal.5 +/- .5
Toe-In in Inches
Fraction0 +/- 3/32
Decimal0 +/- .09
Toe-In in Degrees
Fraction0 +/- 3/16
Decimal0 +/- .19
Toe-Out in Turns
Inner(1)
Outer(1)
Steering Axis Inclination (SAI)7 3/8°
(1) Information not available.
(1)Information not available.

WHEEL ALIGNMENT SPECIFICATIONS (TROOPER II)
