IDENTIFICATION
| Model | Transmission |
|---|---|
| Impulse | Model AW03-70 & AW03-72L |
AUTOMATIC TRANSMISSION APPLICATIONS
SERVICE INTERVALS
Check fluid at every engine oil change. Under normal conditions, replace fluid and oil screen every 30,000 miles. Under severe conditions, change oil and screen at 15,000 mile intervals.
CHECKING FLUID LEVEL
- Park vehicle on level surface. Place selector lever in "P" position, set parking brake and run engine to operating temperature. Apply brake pedal. Move shift lever through each gear. Place shift lever in "P" position.
- With engine idling, clean dipstick and insert. Remove dipstick and check level reading. Fluid level should be between dimples of "HOT" range.
RECOMMENDED FLUID
Use Dexron II automatic transmission fluid in all transmissions and transfer chain cases.
FLUID CAPACITY
| Application | Qts. (L) |
|---|---|
| Impulse | 6.9 (6.5) |
TRANSMISSION REFILL CAPACITIES
DRAINING & REFILLING
- Remove drain plug and drain fluid. Remove oil pan. Remove oil screen. Clean oil pan, magnet, and oil screen in clean solvent and dry.
- Install oil screen. Tighten bolts to 48 INCH lbs. (5.5 N.m).
- Set magnet on oil pan so that it rests directly below oil screen. Install oil pan. Tighten bolts to specification. Install filler tube clip bolt (if equipped) and tighten to 29 ft. lbs. (39 N.m).
- Install drain plug using a new gasket. Tighten to 11-14 ft. lbs. (15-19 N.m). Add about 2.1 qts. (2.0L) of ATF. Check fluid level. Add ATF as necessary to bring fluid to proper level.
| Model | INCH Lbs. (N.m) |
|---|---|
| Impulse | 40 (4.5) |
OIL PAN BOLT TORQUE SPECIFICATIONS
Scheme 1
- Loosen throttle valve cable adjusting nuts. Ensure carburetor throttle adjusting screw is in contact with idle stop.
- Adjust setting of outer cable. On Impulse, ensure distance between upper face of rubber boot on outer cable and inner cable stopper is.032-.059" (0.8-1.5 mm). (Scheme 1)
- Tighten adjusting nuts. Ensure stroke of inner cable from normal idling position to wide open throttle is 1.30-1.36" (32.0-34.5 mm).
SHIFT LINKAGE
- Loosen shift control rod adjusting nuts on transmission end of shift linkage. Ensure that transmission lever is in the "N" position.
- Ensure gearshift lever is in the "N" position. Tighten adjusting nuts. Road test vehicle. Ensure shift lever moves properly and transmission operates smoothly.
NEUTRAL SAFETY SWITCH
Remove gearshift lever console. Loosen switch retaining screws (near base of gearshift lever). Place selector lever in the "N" position. Adjust switch so vehicle will only start in the "P" or "N" positions. Tighten retaining screws.
