Starting System: Overview Infiniti QX80 I

Starter 6 illustrations ~150 words

Component Description

Component partDescription
BCMBCM controls the starter relay inside IPDM E/R.
IPDM E/RCPU inside IPDM E/R controls the starter control relay.
Starter motorThe starter motor plunger closes and the motor is supplied with battery power, which in turn cranks the engine, when the "S" terminal is supplied with electric power.
TCMTCM supplies power to the starter relay and starter control relay inside IPDM E/R when the selector lever is shifted to the P or N position.

Scheme 1

Scheme 1: System Diagram

System Description

  1. When selector lever is P or N, power is supplied to starter relay and starter control relay by TCM. And BCM and IPDM E/R (CPU) detect selector lever P/N condition by the inputted signal.
  2. When starter operating condition is satisfied, IPDM E/R turns starter control relay ON by starter control relay control signal.
  3. When engine cranking condition is satisfied, BCM turns starter relay ON by starter relay control signal.
  4. Then battery power is supplied to starter motor ("S" terminal) through starter control relay and starter relay. And IPDM E/R (CPU) detect starter relay condition by the inputted signal.

Scheme 2

Scheme 2: Wiring Diagram

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

To test the starting system, use the following special service tool

  1. GR8-1200 NI Multitasking battery and electrical diagnostic station

Note. Refer to the diagnostic station Instruction Information for proper starting system diagnosis procedures.

Scheme 6

Scheme 6: OVERALL SEQUENCE
