INSTALLATION Infiniti QX80 I

Interior: Removal & Installation 5 illustrations ~258 words

INSTALLATION

Note the following items, and install in the reverse order of removal.

CAUTIONVisually check the clips, pawls and metal clip for deformation and damage during installation. Replace with new ones if necessary. When installing front door finisher, check that clips, pawls and metal clip are securely fitted in body panel holes, and press them in.

Scheme 133

Scheme 133: Exploded View
Scheme 133: Exploded View
CAUTIONWhen removing, always use a remover tool that is made of plastic. Never damage the body.

Scheme 134

Scheme 134: REMOVAL
Scheme 134: REMOVAL

Scheme 135

Scheme 135
Scheme 135

Scheme 136

Scheme 136
Scheme 136
  1. Fully open door window.
  2. Remove door finisher cap (1) using a small flat-bladed screwdriver (A) as shown by the arrow in the figure below, and then remove rear door finisher mounting bolt. CAUTION: Use a small flat-bladed screwdriver wrapped in tape (B).
  3. Insert a remover tool (A) between rear door grip cap (1) and rear door grip to disengage rear door grip cap fixing pawls as shown by the arrow in the figure below, and then remove fixing screws.
  4. Remove step lamp, and then disconnect step lamp harness connector. Refer to " «REMOVAL AND INSTALLATION»(ref-618071-S30249282292014052700000) ".
  5. Remove bumper rubber.
  6. Insert a remover tool (A) between rear door finisher and rear door panel to disengage the clips as shown by the arrow in the figure below. CAUTION: Insert a remover tool into the part shown in the figure above (between the clips and the door panel).
  7. Disconnect mood lamp harness connector.
  8. Disconnect power window switch harness connector and clamp.
  9. Disconnect lock knob cable and inside handle cable from rear inside handle.
  10. Remove rear door finisher from rear door panel.
  11. Remove the following parts after removing rear door finisher. Mood lamp. Power window switch. Refer to " «REMOVAL AND INSTALLATION»(ref-618037-S30401481672014052700000) ". Rear door inside handle. Refer to " «INSIDE HANDLE: REMOVAL AND INSTALLATION»(ref-618038-S05697587432014052700000) ". Rear door tweeter. Refer to " «REMOVAL AND INSTALLATION»(ref-618082-S38669051482014052700000) ".

Note the following items, and install in the reverse order of removal.

CAUTIONVisually check the clips and pawls for deformation and damage during installation. Replace with new ones if necessary. When installing rear door finisher, check that clips and pawls are securely fitted in body panel holes, and press them in.

Scheme 137

Scheme 137: Exploded View
Scheme 137: Exploded View
