Infiniti QX60 II (2021-2024) combination meter Wiring diagrams

ACTIVE GRILLE SHUTTER BLK WIRE BLU WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM ECM (TOP OF TRANSMISSION) FUSE 6 FUSE 83 FUSE BLOCK (J/B) GRY WIRE HOT W/ ECM RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IGN IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LIN LT BLU WIRE PPL/TAN WIRE RED WIRE TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER YEL WIRE

BATT PWR SPLY (FUSE) BCM (BODY CONTROL MODULE) (LEFT SIDE OF DASH) BELT IND BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE IND BRN WIRE BUZZER CAN L CAN-H COMBINATION METER COMBINATION SW INPUT 1 COMBINATION SW INPUT 2 COMBINATION SW INPUT 2 PPL COMBINATION SW INPUT 1 COMBINATION SW INPUT 3 COMBINATION SW INPUT 4 COMBINATION SW INPUT 5 COMBINATION SW INPUT 6 COMBINATION SW OUTPUT 1 COMBINATION SW OUTPUT 2 COMBINATION SW OUTPUT 3 COMBINATION SW OUTPUT 4 COMBINATION SW OUTPUT 4 PNK COMBINATION SW OUTPUT 3 WIRE COMBINATION SW OUTPUT 5 COMBINATION SW OUTPUT 6 COMBINATION SWITCH (LIGHTING, TURN SIGNAL SWITCH) COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 29 FUSE 6 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED INTELLIGENT KEY UNIT INTELLIGENT KEY WARNING BUZZER LEFT FRONT DOOR LOCK ASSEMBLY LEFT FRONT SEAT BELT BUCKLE SWITCH LF DOOR SW LF SEAT BELT BUCKLE SW LT BLU WIRE LT GRN WIRE MASTER SPEAKER PASSIVE RESTRAINTS SYSTEM PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/RED WIRE PPL/TAN WIRE PPL/WHT WIRE RED WIRE RIGHT END OF DASH) STEERING COLUMN ASSEMBLY TAN WIRE UNIFIED METER CONTROL UNIT W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

ACCESSORY ACTIVATION LINE AV CONTROL UNIT (UNDER CENTER CONSOLE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CHASSIS CAN COMM 3 H CHASSIS CAN COMM 3 L COMBINATION METER DIAGNOSTIC CAN COMM H DIAGNOSTIC CAN COMM L DRIVETRAIN CAN COMM 2-H DRIVETRAIN CAN COMM 2-L ETHERNET ETHERNET RX- ETHERNET TX- FUSE 16 FUSE 40 FUSE 9 FUSE BLOCK (J/B) GND 2 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IGN IT CAN COMM H IT CAN COMM L ITS CAN COMM 1-H ITS CAN COMM 1-L ITS CAN COMM 4-H ITS CAN COMM 4-L LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL/LT BLU WIRE RED WIRE SHIELD TAN WIRE VEHICLE CAN COMM 3-H VEHICLE CAN COMM 3-L W/ 7 INCH INFORMATION DISPLAY METER W/ AROUND VIEW MONITOR SYSTEM W/ FULL TFT METER W/O AROUND VIEW MONITOR SYSTEM W/O BOSE AUDIO SYSTEM WHT WIRE YEL WIRE

ACCESSORY PWR SUPPLY ADAS CONTROL UNIT 2 (UNDER LEFT CENTER OF DASH) AUTOMATIC BRAKE HOLD SW AUTOMATIC BRAKE HOLD SWITCH AUTOMATIC BRAKE HOLD SWITCH IND BATT PWR SUPPLY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-L AUTOMATIC BRAKE HOLD SW IND CHASSIS CONTROL MODULE (LEFT END OF DASH) COMBINATION METER COMPUTER DATA LINES SYSTEM DISPLAY DISTANCE SENSOR DOWN SWITCH DRIVE MODE SWITCH DRV MODE SW (ECO) DRV MODE SW (SPORT) EXTENDED STORAGE FUSE SW FRONT CAMERA UNIT (OVERHEAD CENTER CONSOLE) FUSE 11 FUSE 20 FUSE 30 FUSE 40 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED IC CAN H IC CAN L LT BLU WIRE PARKING BAKE SWITCH PNK WIRE PPL PPL/BRN WIRE PPL/GRN WIRE PPL/TAN WIRE RED WIRE STEERING ANGLE SENSOR (UPPER STEERING COLUMN) UNIFIED METER CONTROL UNIT (W/ INFORMATION UP SWITCH W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

ABS ACTUATOR, ELECTRIC UNIT (CONTROL UNIT) AUTOMATIC BRAKE HOLD SWITCH AUTOMATIC BRAKE HOLD SWITCH IND BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM E-PARK IND (RED) WIRE E-PARK WARNING IND (YELLOW) ELECTRONIC SUSPENSION SYSTEM FUSE 20 FUSE 32 FUSE 6 FUSE BLOCK (J/B) FUSE, FUSIBLE LINK, RELAY BOX FUSIBLE LINK T GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED IGN SIG IGNITION SWITCH ON POWER SUPPLY ILL LEFT PARKING BRAKE ACTUATOR LT BLU WIRE MOTOR LH (+) MOTOR RH (+) MOTOR RH (-) MOTOR LH (-) PARKING BRAKE SWITCH (ON PARKING BRAKE PEDAL ASSEMBLY) PARKING BRAKE SWITCH IND PARKING BRAKE SWITCH INDICATOR PARKING BRAKE SWITCH INPUT 1 PARKING BRAKE SWITCH INPUT 2 PARKING BRAKE SWITCH OUTPUT 1 PARKING BRAKE SWITCH OUTPUT 2 PNK WIRE PPL PPL/TAN WIRE RED WIRE RIGHT PARKING BRAKE ACTUATOR TAN WIRE UNIFIED METER CONTROL UNIT VALVE POWER SUPPLY W/ 7 INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

ANTI- DAZZLING INSIDE MIRROR AUDIO SPEAKER AMP AUTOMATIC BACK DOOR CONTROL MODULE AUTOMATIC DRIVE POSITIONER CONTROL UNIT AV CONTROL UNIT BCM (BODY CONTROL MODULE) BLU WIRE BOSE SPEAKER AMP BRN WIRE COMBINATION METER DISPLAY UNIT DRIVER SEAT CONTROL UNIT EXTENDED STORAGE SWITCH FROM ACCESSORY RELAY (DIAGRAM 6 OF 8) FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 8) FRONT AUXILIARY INPUT JACKS FUSE 12 FUSE 14 FUSE 15 FUSE 21 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 53 FUSE 54 FUSE 55 FUSE 56 FUSE 57 FUSE 58 FUSE AA FUSE DD GRN WIRE HANDS FREE SENSOR CONTROL UNIT LEFT SEAT MEMORY SWITCH LT GRN WIRE PASSENGER SEAT CONTROL UNIT PNK PNK WIRE PNK WIRE PPL PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE RIGHT LUMBAR SUPPORT SWITCH RIGHT POWER SEAT SWITCH RIGHT SEAT MEMORY SWITCH SEAT BACK POWER RETURN CONTROL UNIT SECOND ROW SEAT POWER WALK IN CONTROL UNIT STOP LAMP SWITCH TAN WIRE TO IGNITION RELAY-2 (DIAGRAM 5 OF 8) TO RIGHT ACCESSORY PRE-WIRE (DIAGRAM 7 OF 8) W/ 2 WAY LUMBAR SUPPORT SYSTEM W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER W/O BOSE W/O PASSENGER MEMORY SEAT WHT WIRE YEL WIRE

ACC PWR SPLY AUTO ANTI-DAZZLING INSIDE MIRROR BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CHASSIS CONTROL MODULE COMBINATION METER COMPUTER DATA LINES SYSTEM CONDENSER 1 ELECTRIC INTAKE VALVE TIMING CONTROL MODULE EPS CONTROL UNIT FROM FUSE 73 (DIAGRAM 4 OF 8) FROM FUSIBLE LINK BOX (BATTERY) (DIAGRAM 1 OF 8) FUSE 10 FUSE 11 FUSE 4 FUSE 5 FUSE 6 FUSE 8 FUSE 81 GREEN IND GRN WIRE GRY WIRE IGNITION COIL 1 (W/ POWER TRANSISTOR) IGNITION COIL 2 (W/ POWER TRANSISTOR) IGNITION COIL 3 (W/ POWER TRANSISTOR) IGNITION COIL 4 (W/ POWER TRANSISTOR) IGNITION COIL 5 (W/ POWER TRANSISTOR) IGNITION COIL 6 (W/ POWER TRANSISTOR) IGNITION RELAY 1 INTELLIGENT REAR VIEW MIRROR IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LOOP WIRE LT BLU WIRE LT GRN WIRE ORG IND WIRE PNK WIRE PPL PPL/BRN WIRE PPL/GRN WIRE PPL/TAN WIRE REAR WINDOW DEFOGGER RELAY RED WIRE STEERING ANGLE SENSOR TAN WIRE TO FUSE 9 (DIAGRAM 8 OF 8) TO INVERTER UNIT (DIAGRAM 5 OF 8) TO LEFT ACCESSORY PRE-WIRE (DIAGRAM 7 OF 8) TO RIGHT ACCESSORY PRE-WIRE (DIAGRAM 7 OF 8) TOTAL ILLUMINATION CONTROL UNIT TRAILER TOW RELAY 2 W/ 7 INCH INFORMATION DISPLAY METER W/ AUTO ANTI-DAZZLING INSIDE MIRROR W/ FULL TFT METER W/ HOMELINK UNIVERSAL TRANSCEIVER W/ INTELLIGENT REAR VIEW MIRROR W/O HOMELINK UNIVERSAL TRANSCEIVER WHT WIRE WIRELESS CHARGER INDICATOR WIRELESS CHARGER UNIT WIRELESS CHG IND (GREEN) SIG WIRELESS CHG IND (ORANGE) SIG WIRELESS CHG IND GND

8 P/R SPEED 8 P/R SPEED OUTPUT BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE COMBINATION METER FUSE 58 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR DOOR LOCK ASSEMBLY (DOOR SWITCH) LEFT REAR DOOR SWITCH LEFT SEAT ANGLE SENSOR LEFT SEAT WALK IN MOTOR LEFT WALK IN BACK SWITCH LEFT WALK IN SIDE SWITCH LH REAR DOOR SWITCH LH SEAT ANGLE SIG LH SIDE SWITCH SIG LH WALK IN MOTOR + LT BLU WIRE MOTOR PNK BATT WIRE PNK WIRE PPL PPL/BLK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/YEL WIRE RED WIRE RH BACK SWITCH SIG RH REAR DOOR SWITCH LH BACK SWITCH SIG RH SEAT ANGLE SIG RH SIDE SWITCH SIG RH WALK IN MOTOR - RIGHT REAR DOOR LOCK ASSEMBLY (DOOR SWITCH) RIGHT SEAT ANGLE SENSOR RIGHT SEAT WALK IN MOTOR RIGHT WALK IN BACK SWITCH RIGHT WALK IN SIDE SWITCH SECOND ROW SEAT POWER WALK IN CONTROL UNIT SENS GND SIG SWITCH GND SWITCH ILL SWITCH ILLUMINATION SWITCH SIG TAN WIRE UNIFIED METER CONTROL UNIT (W/ INFORMATION DISPLAY) W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

BAT PWR SPLY BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM D POS IND D POS IND PNK ELECTRIC SHIFT SENS GND 2 WIRE ELECTRIC SHIFT CONTROL MODULE (UNDER CENTER CONSOLE) ELECTRIC SHIFT CONTROL SYSTEM IND ELECTRIC SHIFT SELECTOR ELECTRIC SHIFT SENS 1 ELECTRIC SHIFT SENS 5 ELECTRIC SHIFT SENS 2 ELECTRIC SHIFT SENS 3 ELECTRIC SHIFT SENS 4 ELECTRIC SHIFT SENS 5 ELECTRIC SHIFT SENS 6 ELECTRIC SHIFT SENS 7 ELECTRIC SHIFT SENS 7 ELECTRIC SHIFT SENS PWR SPLY 2 ELECTRIC SHIFT SENS 8 ELECTRIC SHIFT SENS GND 1 ELECTRIC SHIFT SENS GND 2 ELECTRIC SHIFT SENS PWR SPLY ELECTRIC SHIFT SENS PWR SPLY 1 ELECTRIC SHIFT SENS PWR SPLY 1 ELECTRIC SHIFT SENS 1 FUSE 21 FUSE 40 FUSE 44 FUSE 6 FUSE 73 FUSE BLOCK (J/B) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ ACCESSORY RELAY ENERGIZED HOT W/ IGNITION RELAY 1 ENERGIZED HOT W/ IGNITION RELAY ENERGIZED IGN SIG IGNITION SW 1 IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) LT GRN WIRE M POS IND N POS IND P POS IND P POS SW 1 P POS SW 2 P POS SW 2 PNK M POS IND WIRE PNK ELECTRIC SHIFT SENS PWR SPLY 2 ELECTRIC SHIFT SENS 2 WIRE PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/TAN WIRE PWR GND 1 PWR GND 2 PWR SPLY 1 IN PWR SPLY 2 R POS IND R POS IND PPL N POS IND RED WIRE STOP LAMP SW 2 STOP LAMP SWITCH TAN WIRE UNIFIED METER CONTROL UNIT W/ 7 INFORMATION DISPLAY METER W/ FULL TFT METER WHT WIRE YEL WIRE

BATT PWR SPLY (FUSE) BCM (BODY CONTROL MODULE) BLK WIRE BLU WIRE CAN L CAN-H COMBINATION METER COMPUTER DATA LINES SYSTEM FUSE 15 FUSE 29 FUSE 6 FUSE BLOCK (J/B) HOT AT ALL TIMES HOT W/ IGNITION RELAY 1 ENERGIZED MASTER SPEAKER PPL/BLU WIRE PPL/GRN WIRE PPL/TAN WIRE PPL/WHT WIRE RED WIRE TAN WIRE TIRE PRESSURE IND TIRE PRESSURE SENSOR UNIFIED METER CONTROL UNIT W/ 7 INCH INFORMATION DISPLAY METER W/ FULL TFT METER
