Transfer: Maintenance Infiniti QX56 I

Transfer Case 8 illustrations ~206 words

DRAINING

Refer to " CHANGING TRANSFER FLUID ".

FLUID LEAKAGE AND FLUID LEVEL

Refer to " CHECKING TRANSFER FLUID ".

Scheme 248

Scheme 248: Cross-section View

Scheme 249

Scheme 249: POWER TRANSFER DIAGRAM

Scheme 250

Scheme 250: POWER TRANSFER FLOW

Scheme 251

Scheme 251: CONTROL SYSTEM

Scheme 252

Scheme 252: ALL-MODE 4WD Transfer Basic Control

Scheme 253

Scheme 253: Hydraulic Control Circuits

Scheme 254

Scheme 254: TRANSFER MOTOR

Scheme 255

Scheme 255
  1. The transfer motor drives the sub-oil pump to provide proper lubrication and oil pressure control when the vehicle is at standstill, during low-speed operations or is being driven in reverse.
  2. The main oil pump is operated by the driving force of the mainshaft. In other words, sufficient oil pressure buildup does not occur when the vehicle is at standstill or during low-speed operations. While the vehicle is being driven in reverse, the main oil pump rotates in the reverse direction. Therefore the main oil pump does not discharge oil pressure. During any of the above vehicle operations, the transfer motor drives the sub-oil pump to compensate for insufficient oil pressure.
  3. The transfer motor operates as follows. The motor relay turns OFF in the 2WD mode. The motor relay operates as described in the table below in modes other than the 2WD mode. Table 1 Table 2
  4. 4WD shift switch, PNP switch, Neutral-4LO switch, vehicle speed sensor and throttle position sensor are used in conjunction with the transfer motor.
