Outer Socket and Inner Socket Swing Torque
Hook a spring balance at the point shown in the figure. Confirm if the reading is within the specification. When ball stud and inner socket start moving the measured value must be within the specification. If the reading is outside the specification, replace socket.
Scheme 1
| Item | Outer socket | Inner socket |
|---|---|---|
| Measuring point | Cotter pin hole of stud | Shown as "L": 83.2 mm (3.276 in) |
| Swing torque | 0.3-2.9 N.m (0.03-0.29 kg-m, 3-25 in-lb) | 1.0-7.8 N.m (0.11-0.79 kg-m, 9-69 in-lb) |
| Measuring value | 4.84-46.7 N (0.50-4.7 kg, 4-34 lb) | 12.1-93.7 N (1.3-9.5 kg, 9-69 lb) |
OUTER & INNER SOCKET SPECIFICATIONS
Outer Socket and Inner Socket Rotating Torque
Using Tool, check if reading is within the value specified below. If the value is outside the standard, replace outer sockets.
Scheme 2
- Tool number: ST3127S000 (J-25765-A)
- Rotating torque: 0.3-2.9 N.m (0.03-0.29 kg-m, 3-25 in-lb)
