When a DTC is stored in ECM
When a DTC is stored in ECM and MIL is ON, a permanent DTC is erased with MIL shutoff if the same malfunction is not detected after performing the driving pattern for MIL shutoff three times in a row.
Scheme 45
When a DTC is not stored in ECM
The erasing method depends on a permanent DTC stored in ECM. Refer to the following table.
Note. If the applicable permanent DTC includes multiple groups, perform the procedure of Group B first. If the permanent DTC is not erased, perform the procedure of Group A.
| X: Applicable -: Not applicable | |||
|---|---|---|---|
| Group (1) | Perform "DTC CONFIRMATION PROCEDURE" for applicable DTCs. | Driving pattern | |
| B | D | ||
| A | X | ||
| B | X | X | |
| (1) For group, refer to " DTC INDEX ". | |||
| (1) | For group, refer to " DTC INDEX ". |
PERMANENT DTC ITEM
For permanent DTC items, MIL turns ON. Refer to " DTC INDEX ".
Scheme 46
Scheme 47
- CHECK DTC Check DTC. Is any DTC detected? YES: Repair malfunction(s) and erase DTC. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-616999-S00404725702014052000000) ", " «CONSULT FUNCTION»(ref-616999-S11342544512014052000000) ". NO: GO TO 2.
- CHECK PERMANENT DTC With CONSULT Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select "PERMANENT DTC STATUS" mode with CONSULT. With GST Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select Service $0A with GST. Is any permanent DTC detected? YES: GO TO 3. NO: END
- PERFORM DTC CONFIRMATION PROCEDURE Perform "DTC CONFIRMATION PROCEDURE" for DTCs which are the same as permanent DTCs stored in ECM. Refer to " «DTC INDEX»(ref-616998-S13806969972014052000000) ". : GO TO 4.
- CHECK PERMANENT DTC With CONSULT Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select "PERMANENT DTC STATUS" mode with CONSULT. With GST Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select Service $0A with GST. Is any permanent DTC detected? YES: GO TO 1 . NO: END
Scheme 48
Note. Drive the vehicle according to only driving patterns indicating "INCMP" in driving patterns B and D on the "PERMANENT DTC STATUS" screen.
- CHECK DTC Check DTC. Is any DTC detected? YES: Repair malfunction(s) and erase DTC. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-616999-S00404725702014052000000) ", " «CONSULT FUNCTION»(ref-616999-S11342544512014052000000) ". NO: GO TO 2.
- CHECK PERMANENT DTC With CONSULT Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select "PERMANENT DTC STATUS" mode with CONSULT. With GST Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select Service $0A with GST. Is any permanent DTC detected? YES: GO TO 3. NO: END
- DRIVE DRIVING PATTERN B CAUTION: Always drive at a safe speed. Never erase self-diagnosis results. If self-diagnosis results are erased during the trip of driving pattern B or D, the counter of driving pattern B and D is reset. With CONSULT Start engine and warm it up to normal operating temperature. Use "PERMANENT DTC WORK SUPPORT" mode with CONSULT to drive the vehicle according to driving pattern B. Refer to " «CONSULT FUNCTION»(ref-616999-S11342544512014052000000) ", " «DIAGNOSIS DESCRIPTION: DRIVING PATTERN»(ref-616999-S13581141382014052000000) ". With GST Start engine and warm it up to normal operating temperature. Drive the vehicle according to driving pattern B. Refer to " «DIAGNOSIS DESCRIPTION: DRIVING PATTERN»(ref-616999-S13581141382014052000000) ". : GO TO 4.
- CHECK PERMANENT DTC With CONSULT Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select "PERMANENT DTC STATUS" mode with CONSULT. With GST Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select Service $0A with GST. Is any permanent DTC detected? YES: GO TO 5. NO: END
- DRIVE DRIVING PATTERN D CAUTION: Always drive at a safe speed. Never erase self-diagnosis results. If self-diagnosis results are erased during the trip of driving pattern B or D, the counter of driving pattern B and D is reset. Drive the vehicle according to driving pattern D. Refer to " «DIAGNOSIS DESCRIPTION: DRIVING PATTERN»(ref-616999-S13581141382014052000000) ". : GO TO 6.
- CHECK PERMANENT DTC With CONSULT Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select "PERMANENT DTC STATUS" mode with CONSULT. With GST Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Turn ignition switch OFF and wait at least 10 seconds. Turn ignition switch ON. Select Service $0A with GST. Is any permanent DTC detected? YES: GO TO 1 . NO: END
Scheme 49
GST (Generic Scan Tool)
When GST is connected with a data link connector equipped on the vehicle side, it will communicate with the control unit equipped in the vehicle and then enable various kinds of diagnostic tests. Refer to " DIAGNOSIS DESCRIPTION ".
Note. Service $0A is not applied for regions where it is not mandated.
DTC AND 1ST TRIP DTC
The 1st trip DTC (whose number is the same as the DTC number) is displayed for the latest self-diagnostic result obtained. If the ECM memory was cleared previously, and the 1st trip DTC did not recur, the 1st trip DTC will not be displayed.
If a malfunction is detected during the 1st trip, the 1st trip DTC is saved in the ECM memory. The MIL will not light up (two trip detection logic). If the same malfunction is not detected in the 2nd trip (meeting the required driving pattern), the 1st trip DTC is cleared from the ECM memory. If the same malfunction is detected in the 2nd trip, both the 1st trip DTC and DTC are saved in the ECM memory and the MIL lights up. In other words, the DTC is stored in the ECM memory and the MIL lights up when the same malfunction occurs in two consecutive trips. If a 1st trip DTC is stored and a non-diagnostic operation is performed between the 1st and 2nd trips, only the 1st trip DTC will continue to be stored. For malfunctions that blink or light up the MIL during the 1st trip, the DTC and 1st trip DTC are stored in the ECM memory.
For malfunctions in which 1st trip DTCs are displayed, refer to " DTC INDEX ". These items are required by legal regulations to continuously monitor the system/component. In addition, the items monitored non-continuously are also displayed on CONSULT.
1st trip DTC is specified in Service $07 of SAE J1979/ISO 15031-5. 1st trip DTC detection occurs without illuminating the MIL and therefore does not warn the driver of a malfunction.
When a 1st trip DTC is detected, check, print out or write down and erase (1st trip) DTC and Freeze Frame data as specified in Work Flow procedure Step 2, refer to " WORK FLOW ". Then perform DTC Confirmation Procedure or Component Function Check to try to duplicate the malfunction. If the malfunction is duplicated, the item requires repair.
RELATIONSHIP BETWEEN MIL, 1ST TRIP DTC, DTC, AND DETECTABLE ITEMS
- When a malfunction is detected for the first time, the 1st trip DTC and the 1st trip freeze frame data are stored in the ECM memory.
- When the same malfunction is detected in two consecutive trips, the DTC and the freeze frame data are stored in the ECM memory, and the MIL will come on.
- The MIL will turn OFF after the vehicle is driven 3 times (driving pattern B) with no malfunction. The drive is counted only when the recorded driving pattern is met (as stored in the ECM). If another malfunction occurs while counting, the counter will reset.
- The DTC and the freeze frame data will be stored until the vehicle is driven 40 times (driving pattern A) without the same malfunction recurring (except for Misfire and Fuel Injection System). For Misfire and Fuel Injection System, the DTC and freeze frame data will be stored until the vehicle is driven 80 times (driving pattern C) without the same malfunction recurring. The "TIME" in "SELF-DIAGNOSTIC RESULTS" mode of CONSULT will count the number of times the vehicle is driven.
- The 1st trip DTC is not displayed when the self-diagnosis results in OK for the 2nd trip.
ON BOARD DIAGNOSIS ITEM
The on board diagnostic system has the following functions.
| Diagnostic test mode | Function |
|---|---|
| Bulb check | MIL can be checked. |
| SRT status | ECM can read if SRT codes are set. |
| Malfunction warning | If ECM detects a malfunction, it illuminates or blinks MIL to inform the driver that a malfunction has been detected. |
| Self-diagnostic results | DTCs or 1st trip DTCs stored in ECM can be read. |
| Accelerator pedal released position learning | ECM can learn the accelerator pedal released position. Refer to " ACCELERATOR PEDAL RELEASED POSITION LEARNING: DESCRIPTION ". |
| Throttle valve closed position learning | ECM can learn the throttle valve closed position. Refer to " THROTTLE VALVE CLOSED POSITION LEARNING: DESCRIPTION ". |
| Idle air volume learning | ECM can learn the idle air volume. Refer to " IDLE AIR VOLUME LEARNING: DESCRIPTION ". |
| Mixture ratio self-learning value clear | Mixture ratio self-learning value can be erased. Refer to " MIXTURE RATIO SELF-LEARNING VALUE CLEAR: DESCRIPTION ". |
SELF-DIAGNOSTIC RESULTS MODE
Description
This function allows to indicate DTCs or 1st trip DTCs stored in ECM according to the number of times MIL is blinking.
How to Set Self-diagnostic Results Mode
Note. It is better to count the time accurately with a clock. It is impossible to switch the diagnostic mode when an accelerator pedal position sensor circuit has a malfunction. After ignition switch is turned off, ECM is always released from the "self-diagnostic results" mode.
Scheme 50
- Confirm that accelerator pedal is fully released, turn ignition switch ON and wait 3 seconds.
- Repeat the following procedure quickly five times within 5 seconds. Fully depress the accelerator pedal. Fully release the accelerator pedal.
- Wait 7 seconds, fully depress the accelerator pedal and keep it depressed for approx. 10 seconds until the MIL starts blinking. NOTE: Do not release the accelerator pedal for 10 seconds if MIL starts blinking during this period. This blinking is displaying SRT status and is continued for another 10 seconds.
- Fully release the accelerator pedal. ECM has entered to "Self-diagnostic results" mode. NOTE: Wait until the same DTC (or 1st trip DTC) appears to completely confirm all DTCs.
How to Read Self-diagnostic Results
The DTC and 1st trip DTC are indicated by the number of blinks of the MIL as shown below.
The DTC and 1st trip DTC are displayed at the same time. If the MIL does not illuminate in diagnostic test mode I (Malfunction warning), all displayed items are 1st trip DTCs. If only one code is displayed when the MIL illuminates in "malfunction warning" mode, it is a DTC; if two or more codes are displayed, they may be either DTCs or 1st trip DTCs. DTC No. is same as that of 1st trip DTC. These unidentified codes can be identified by using the CONSULT or GST. A DTC will be used as an example for how to read a code.
Scheme 51
A particular trouble code can be identified by the number of four-digit numeral flashes per the following.
| Number | 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | A | B | C | D | E | F |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Flashes | 10 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 11 | 12 | 13 | 14 | 15 | 16 |
The length of time the 1, 000th-digit numeral flashes on and off is 1.2 seconds consisting of an ON (0.6-seconds) - OFF (0.6-seconds) cycle.
The 100th-digit numeral and lower digit numerals consist of a 0.3-seconds ON and 0.3-seconds OFF cycle. A change from one digit numeral to another occurs at an interval of 1.0-second OFF. In other words, the later numeral appears on the display 1.3 seconds after the former numeral has disappeared.
A change from one trouble code to another occurs at an interval of 1.8-seconds OFF.
In this way, all the detected malfunctions are classified by their DTC numbers. The DTC 0000 refers to no malfunction. Refer to " DTC INDEX ".
How to Erase Self-diagnostic Results
By performing this procedure, ECM memory is erased and the following diagnostic information is erased as well.
- Diagnostic trouble codes
- 1st trip diagnostic trouble codes
- Freeze frame data
- 1st trip freeze frame data
- System readiness test (SRT) codes
- Test values
Note. Also, if a battery terminal is disconnected, ECM memory is erased and the diagnostic information as listed above is erased. (The amount of time required for erasing may vary from a few seconds to several hours.)
- Turn ignition switch OFF and wait at least 10 seconds.
- Turn ignition switch ON.
- Turn ignition switch OFF and wait at least 10 seconds.
- Turn ignition switch ON.
- Set ECM in "self-diagnostic results" mode.
- The diagnostic information has been erased from the backup memory in the ECM. Fully depress the accelerator pedal and keep it depressed for more than 10 seconds.
- Fully release the accelerator pedal, and confirm the DTC 0000 is displayed.
SELF DIAGNOSTIC RESULT MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip DTC, refer to " DTC INDEX ".
How to Read DTC and 1st Trip DTC
DTCs and 1st trip DTCs related to the malfunction are displayed in "self-diag results".
- When ECM detects a 1st trip DTC, 1t" is displayed for "TIME".
- When ECM has detected a current DTC, "0" is displayed for "TIME".
- If "TIME" is neither "0" nor "1t", the DTC occurred in the past and ECM shows the number of times the vehicle has been driven since the last detection of the DTC.
How to Erase DTC and 1st Trip DTC
Note. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10 seconds and then turn it ON (engine stopped) again. If the DTC is not for A/T related items (see " DTC INDEX "), skip step 1 .
- Erase DTC in TCM. Refer to " «CONSULT FUNCTION»(ref-617006-S23096265442014052000000) ".
- Select "ENGINE" with CONSULT.
- Select "SELF-DIAG RESULTS".
- Touch "ERASE". (DTC in ECM will be erased.)
| Freeze frame data item (1) | Description |
|---|---|
| DIAG TROUBLE CODE [PXXXX] | The engine control component part/control system has a trouble code that is displayed as PXXXX. (Refer to " DTC INDEX ".) |
| CAL/LD VALUE [%] | The calculated load value at the moment a malfunction is detected is displayed. |
| COOLANT TEMP [°C] or [°F] | The engine coolant temperature at the moment a malfunction is detected is displayed. |
| L-FUEL TRM-B1 [%] | "Long-term fuel trim" at the moment a malfunction is detected is displayed. The long-term fuel trim indicates much more gradual feedback compensation to the base fuel schedule than short-term fuel trim. |
| L-FUEL TRM-B2 [%] | |
| S-FUEL TRM-B1 [%] | "Short-term fuel trim" at the moment a malfunction is detected is displayed. The short-term fuel trim indicates dynamic or instantaneous feedback compensation to the base fuel schedule. |
| S-FUEL TRM-B2 [%] | |
| ENGINE SPEED [RPM] | The engine speed at the moment a malfunction is detected is displayed |
| VEHICL SPEED [km/h] or [mph] | The vehicle speed at the moment a malfunction is detected is displayed |
| ABSOL TH.P/S [%] | The throttle valve opening angle at the moment a malfunction is detected is displayed |
| B/FUEL SCHDL [msec] | The base fuel schedule at the moment a malfunction is detected is displayed |
| INT/A TEMP SE [°C] or [°F] | The intake air temperature at the moment a malfunction is detected is displayed |
| FUEL SYS-B1 | "Fuel injection system status" at the moment a malfunction is detected is displayed. One of the following mode is displayed. Mode2: Open loop due to detected system malfunction Mode3: Open loop due to driving conditions (power enrichment, deceleration enleanment) Mode4: Closed loop - using oxygen sensor(s) as feedback for fuel control Mode5: Open loop - has not yet satisfied condition to go to closed loop |
| FUEL SYS-B2 | |
| INT MANI PRES [kPa] | These items are displayed but are not applicable to this model. |
| COMBUST CONDITION | |
| (1) The items are the same as those of 1st trip freeze frame data. | |
| (1) | The items are the same as those of 1st trip freeze frame data. |
FREEZE FRAME DATA AND 1ST TRIP FREEZE FRAME DATA
ACTIVE TEST MODE
| TEST ITEM | CONDITION | JUDGEMENT | CHECK ITEM (REMEDY) |
|---|---|---|---|
| VENT CONTROL/V | Ignition switch: ON (Engine stopped) Turn solenoid valve ON and OFF with the CONSULT and listen to operating sound. | Solenoid valve makes an operating sound. | Harness and connectors Solenoid valve |
| ENG COOLANT TEMP | Engine: Return to the original trouble condition Change the engine coolant temperature using CONSULT. | If trouble symptom disappears, see CHECK ITEM. | Harness and connectors Engine coolant temperature sensor Fuel injector |
| FUEL INJECTION | Engine: Return to the original trouble condition Change the amount of fuel injection using CONSULT. | If trouble symptom disappears, see CHECK ITEM. | Harness and connectors Fuel injector Air fuel ratio (A/F) sensor 1 |
| FUEL/T TEMP SEN | Change the fuel tank temperature using CONSULT. | ||
| PURG VOL CONT/V | Engine: After warming up, run engine at 1, 500 RPM. Change the EVAP canister purge volume control solenoid valve opening percent using CONSULT. | Engine speed changes according to the opening percent. | Harness and connectors Solenoid valve |
| FUEL PUMP RELAY | Ignition switch: ON (Engine stopped) Turn the fuel pump relay ON and OFF using CONSULT and listen to operating sound. | Fuel pump relay makes the operating sound. | Harness and connectors Fuel pump relay |
| IGNITION TIMING | Engine: Return to the original trouble condition Timing light: Set Retard the ignition timing using CONSULT. | If trouble symptom disappears, see CHECK ITEM. | Perform Idle Air Volume Learning. |
| FAN DUTY CONTROL (1) | Ignition switch: ON Change duty ratio using CONSULT. | Cooling fan speed changes. | Harness and connectors Cooling fan motor Cooling fan relay Cooling fan control module IPDM E/R |
| ALTERNATOR DUTY | Engine: Idle Change duty ratio using CONSULT. | Battery voltage changes. | Harness and connectors IPDM E/R Alternator |
| POWER BALANCE | Engine: After warming up, idle the engine. A/C switch OFF Selector lever: P or N Cut off each injector signal one at a time using CONSULT. | Engine runs rough or dies. | Harness and connectors Compression Fuel injector Power transistor Spark plug Ignition coil |
| (1) Leaving cooling fan OFF with CONSULT while engine is running may cause the engine to overheat. | |||
| (1) | Leaving cooling fan OFF with CONSULT while engine is running may cause the engine to overheat. |
TEST ITEMS DESCRIPTION
DTC WORK SUPPORT MODE
| Test mode | Test item | Corresponding DTC No. |
|---|---|---|
| EVAPORATIVE SYSTEM | EVP SML LEAK P0442 (1) /P1442 (1) | |
| EVP V/S LEAK P0456/P1456 (1) | P0456 | |
| PURG VOL CN/V P1444 | P0443 | |
| PURG FLOW P0441 | P0441 | |
| A/F SEN1 | A/F SEN1 (B1) P1278/P1279 | |
| A/F SEN1 (B1) P1276 | P0130 | |
| A/F SEN1 (B2) P1288/P1289 | ||
| A/F SEN1 (B2) P1286 | P0150 | |
| HO2S2 | HO2S2 (B1) P1146 | P0138 |
| HO2S2 (B1) P1147 | P0137 | |
| HO2S2 (B1) P0139 | P0139 | |
| HO2S2 (B2) P1166 | P0158 | |
| HO2S2 (B2) P1167 | P0157 | |
| HO2S2 (B2) P0159 | P0159 | |
| (1) DTC P0442, P1442 and P1456 does not apply to this models but appears in DTC Work Support Mode screens. | ||
| (1) | DTC P0442, P1442 and P1456 does not apply to this models but appears in DTC Work Support Mode screens. |
TEST ITEMS DESCRIPTION
SRT & P-DTC MODE
SRT STATUS Mode
- For items whose SRT codes are set, "CMPLT" is displayed on the CONSULT screen; for items whose SRT codes are not set, "INCMP" is displayed.
- "SRT STATUS" provides the presence or absence of permanent DTCs stored in ECM memory.
PERMANENT DTC STATUS Mode
How to Display Permanent DTC Status
Scheme 52
- Turn ignition switch OFF and wait at 10 seconds.
- Turn ignition switch ON.
- Turn ignition switch OFF and wait at 10 seconds.
- Turn ignition switch ON. NOTE: Permanent DTCs stored in ECM memory are displayed on the CONSULT screen to show if a driving pattern required for erasing permanent DTCs is complete (CMPLT) or incomplete (INCMP). CAUTION: Since the "PERMANENT DTC STATUS" screen displays the previous trip information, repeat the following twice to update the information: "Ignition switch OFF", "Wait for more than 10 seconds" and "Ignition switch ON".
Note. This mode is not used in regions that permanent DTCs are not regulated by law.
SRT WORK SUPPORT Mode
This mode enables a technician to drive a vehicle to set the SRT while monitoring the SRT status.
PERMANENT DTC WORK SUPPORT Mode
This mode enables a technician to drive a vehicle to complete the driving pattern that is required for erasing permanent DTC.
Note. This mode is not used in regions that permanent DTCs are not regulated by law.
Diagnosis Procedure
- CHECK GROUND CONNECTION Turn ignition switch OFF. Check ground connection M95. Refer to Ground Inspection in " «CIRCUIT INSPECTION»(ref-616989-S29523064592014052000000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace ground connection.
- CHECK ECM GROUND CIRCUIT FOR OPEN AND SHORT-I Disconnect ECM harness connector. Check the continuity between ECM harness connector and ground. ECM Ground Continuity Connector Terminal F101 8 Ground Existed M107 123 124 127 128 Also check harness for short to power. Is the inspection result normal? YES: GO TO 4 . NO: GO TO 3.
- DETECT MALFUNCTIONING PART Check the following. Harness connectors F103, M116 Harness for open or short between ECM and ground : Repair open circuit or short to power in harness or connectors.
- CHECK ECM POWER SUPPLY CIRCUIT-I Reconnect ECM harness connector. Turn ignition switch ON. Check the voltage between ECM harness connector and ground. ECM Voltage + - Connector Terminal Connector Terminal F102 53 M107 128 Battery voltage Is the inspection result normal? YES: GO TO 6 . NO: GO TO 5.
- DETECT MALFUNCTIONING PART Check the following. Harness connectors E13, F40 IPDM E/R harness connector E7 10 A fuse (No. 44) Harness for open or short between ECM and fuse : Repair open circuit, short to ground or short to power in harness or connectors.
- CHECK ECM POWER SUPPLY CIRCUIT-II Turn ignition switch OFF and wait at least 10 seconds. Check the voltage between ECM harness connector terminals as follows. ECM Voltage Connector + - Terminal Terminal M107 125 128 After turning ignition switch OFF, battery voltage will exist for a few seconds, then drop to approximately 0 V. Is the inspection result normal? YES: GO TO 7. NO: GO TO 9 .
- CHECK ECM POWER SUPPLY CIRCUIT-III Turn ignition switch ON. Check the voltage between IPDM E/R harness connector and ground. IPDM E/R Ground Voltage Connector Terminal E7 53 Ground Battery voltage Is the inspection result normal? YES: GO TO 8. NO: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-617019-S21074789862014052000000) ".
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616989-S00672575652014052000000) ". : INSPECTION END
- CHECK ECM POWER SUPPLY CIRCUIT-IV Turn ignition switch OFF and wait at least 10 seconds. Check the voltage between ECM harness connector terminals as follows. ECM Voltage + - Connector Terminal Connector Terminal F101 24 M107 128 Battery voltage Is the inspection result normal? YES: GO TO 13 . NO: GO TO 10.
- CHECK ECM POWER SUPPLY CIRCUIT-V Disconnect ECM harness connector. Disconnect IPDM E/R harness connector. Check the continuity between ECM harness connector and IPDM E/R harness connector. ECM IPDM E/R Continuity Connector Terminal Connector Terminal F101 24 E7 69 Existed Also check harness for short to ground and short to power. Is the inspection result normal? YES: GO TO 12 . NO: GO TO 11.
- DETECT MALFUNCTIONING PART Check the following. Harness or connectors E13, F40 Harness connectors F104, F105 Harness for open or short between ECM and IPDM E/R : Repair open circuit, short to ground or short to power in harness or connectors.
- CHECK 15 A FUSE Disconnect 15 A fuse (No. 50) from IPDM E/R. Check 15 A fuse. Is the inspection result normal? YES: GO TO 15 . NO: Replace 15 A fuse.
- CHECK ECM POWER SUPPLY CIRCUIT-VI Disconnect ECM harness connector. Disconnect IPDM E/R harness connector. Check the continuity between ECM harness connector and IPDM E/R harness connector. ECM IPDM E/R Continuity Connector Terminal Connector Terminal M107 125 E7 49 Existed Also check harness for short to ground and short to power. Is the inspection result normal? YES: GO TO 15 . NO: GO TO 14.
- DETECT MALFUNCTIONING PART Check the following. Harness or connectors E106, M6 Harness for open or short between ECM and IPDM E/R : Repair open circuit, short to ground or short to power in harness or connectors.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616989-S00672575652014052000000) ". Is the inspection result normal? YES: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-617019-S21074789862014052000000) ". NO: Repair open circuit, short to ground or short to power in harness or connectors.
- CHECK GROUND CONNECTION Turn ignition switch OFF. Check ground connection M95. Refer to Ground Inspection in " «CIRCUIT INSPECTION»(ref-616989-S29523064592014052000000) ". Is the inspection result normal? YES: GO TO 2. NO: Repair or replace ground connection.
- CHECK VVEL CONTROL MODULE GROUND CIRCUIT FOR OPEN AND SHORT Disconnect VVEL control module harness connector. Check the continuity between VVEL control module harness connector and ground. VVEL control module Ground Continuity Connector Terminal E14 14 Ground Existed Also check harness for short to power. Is the inspection result normal? YES: GO TO 3. NO: Repair open circuit, short to power in harness connectors.
- CHECK VVEL CONTROL MODULE POWER SUPPLY CIRCUIT-I Reconnect VVEL control module harness connector. Turn ignition switch ON. Check the voltage between VVEL control module harness connector and ground. VVEL control module Voltage Connector + - Terminal Terminal E14 8 14 After turning ignition switch OFF, battery voltage will exist for a few seconds, then drop to approximately 0 V. Is the inspection result normal? YES: GO TO 5 . NO: GO TO 4.
- CHECK VVEL CONTROL MODULE POWER SUPPLY CIRCUIT-II Turn ignition switch OFF and wait at least 10 seconds. Disconnect VVEL control module harness connector. Disconnect IPDM E/R harness connector. Check the continuity between VVEL control module harness connector and IPDM E/R harness connector. VVEL control module IPDM E/R Continuity Connector Terminal Connector Terminal E14 8 E7 49 Existed Also check harness for short to ground and short to power. Is the inspection result normal? YES: " «DIAGNOSIS PROCEDURE»(ref-616999-S20393321332014052000000) " NO: Repair open circuit, short to ground or short to power in harness or connectors.
- CHECK INTERMITTENT INCIDENT Refer to " «INTERMITTENT INCIDENT»(ref-616989-S00672575652014052000000) ". Is the inspection result normal? YES: Replace IPDM E/R. Refer to " «REMOVAL AND INSTALLATION»(ref-617019-S21074789862014052000000) ". NO: Repair open circuit, short to ground or short to power in harness or connectors.
