Scheme 38
Scheme 39
General maintenance includes those items which should be checked during the normal day-to-day operation of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform checks and inspections themselves or have their INFINITI retailers do them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
| Item | Reference |
|---|
| Tires | Check the pressure with a gauge often and always prior to long distance trips. Adjust the pressure in all tires, including the spare, to the pressure specified. Check carefully for damage, cuts or excessive wear. | SERVICE DATA AND SPECIFICATIONS (SDS) |
| Wheel nuts | When checking the tires, make sure no nuts are missing, and check for any loose nuts. Tighten if necessary. | |
| Tire rotation | Tires should be rotated every 5, 000 miles (8, 000 km). | WHEELS (BONDING WEIGHT TYPE) |
| Tire Pressure Monitoring System (TPMS) transmitter components | Replace the TPMS transmitter grommet seal, valve core and cap when the tires are replaced due to wear or age. | TIRE PRESSURE SENSOR |
| Wheel alignment and balance | If the vehicle should pull to either side while driving on a straight and level road, or if you detect uneven or abnormal tire wear, there may be a need for wheel alignment. If the steering wheel or seat vibrates at normal highway speeds, wheel balancing may be needed. For additional information regarding tires, refer to "Important Tire Safety Information" (US) or "Tire Safety Information" (Canada) in the INFINITI Warranty Information Booklet. | WHEEL ALIGNMENT (2WD) WHEEL ALIGNMENT (AWD) WHEEL ALIGNMENT WHEELS (BONDING WEIGHT TYPE) |
| Windshield | Clean the windshield on a regular basis. Check the windshield at least every six months for cracks or other damage. Repair as necessary. | |
| Windshield wiper blades | Check for cracks or wear if they do not wipe properly. | |
| Doors and engine hood | Check that all doors and the engine hood operate smoothly as well as the back door, trunk lid and glass hatch. Also make sure that all latches lock securely. Lubricate if necessary. Make sure that the secondary latch keeps the hood from opening when the primary latch is released. When driving in areas using road salt or other corrosive materials, check lubrication frequently. | LOCKS, HINGES AND HOOD LATCH |
| Lamps | Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other lamps are all operating properly and installed securely. Also check headlamp aim. Clean the headlamps on a regular basis. | |
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle, etc.
| Item | Reference |
|---|
| Warning lamps and chimes | Make sure that all warning lamps and chimes are operating properly. | |
| Windshield wiper and washer | Check that the wipers and washer operate properly and that the wipers do not streak. | |
| Windshield defroster | Check that the air comes out of the defroster outlets properly and in sufficient quantity when operating the heater or air conditioner. | |
| Steering wheel | Check that it has the specified play. Check for changes in the steering condition, such as excessive play, hard steering or strange noises. Free play: Less than 35 mm (1.38 in) | |
| Seats | Check seat position controls such as seat adjusters, seatback recliner, etc. to make sure they operate smoothly and that all latches lock securely in every position. Check that the head restrains move up and down smoothly and that the locks (if equipped) hold securely in all latched positions. Check that the latches lock securely for folding-down rear seatbacks. | |
| Seat belts | Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and retractors) operate properly and smoothly, and are installed securely. Check the belt webbing for cuts, fraying, wear or damage. | SEAT BELT, BUCKLES, RETRACTORS, ANCHORS AND ADJUSTERS |
| Accelerator pedal | Check the pedal for smooth operation and make sure the pedal does not catch or require uneven effort. Keep the floor mats away from the pedal. | |
| Brakes | Check that the brake does not pull the vehicle to one side when applied. | |
| Brake pedal and booster | Check the pedal for smooth operation and make sure it has the proper distance under it when depressed fully. Check the brake booster function. Be sure to keep the floor mats away from the pedal. | PERIODIC MAINTENANCE BRAKE BOOSTER |
| Parking brake | Check that the lever or the pedal has the proper travel and make sure that the vehicle is held securely on a fairly steep hill when only the parking brake is applied. | PERIODIC MAINTENANCE |
| Automatic transmission "Park" mechanism | Check that the lock release button on the selector lever operates properly and smoothly. On a fairly steep hill check that the vehicle is held securely with the selector lever in the P (Park) position without applying any brakes. | |
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
| Item | Reference |
|---|
| Windshield washer fluid | Check that there is adequate fluid in the tank. | |
| Engine coolant level | Check the coolant level when the engine is cold. | PERIODIC MAINTENANCE |
| Radiator and hoses | Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may have accumulated. Make sure the hoses have no cracks, deformation, deterioration or loose connections. | RADIATOR |
| Brake fluid level | Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the reservoir. | BRAKE FLUID LEVEL AND LEAKS |
| Battery | Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. Vehicles operated in high temperatures or under severe conditions require frequent checks of the battery fluid level. | BASIC INSPECTION |
| Engine drive belts | Make sure that no belt is frayed, worn, cracked or oily. | DRIVE BELT |
| Engine oil level | Check the level on the oil level gauge after parking the vehicle on a level spot and turning off the engine. | PERIODIC MAINTENANCE |
| Power steering fluid level and lines | Check the level on the dipstick with the engine off. Check the lines for improper attachment, leaks, cracks, etc. | POWER STEERING FLUID AND LINES |
| Exhaust system | Make sure there are no loose supports, cracks or holes. If the sound of the exhaust seems unusual or there is a smell of exhaust fumes, immediately locate the trouble and correct it. | EXHAUST SYSTEM |
| Underbody | The underbody is frequently exposed to corrosive substances such as those used on icy roads or to control dust. It is very important to remove these substances, otherwise rust will form on the floor pan, frame, fuel lines and around the exhaust system. At the end of winter, the underbody should be thoroughly flushed with plain water, being careful to clean those areas where mud and dirt can easily accumulate. | |
| Fluid leaks | Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has been parked for a while. Water dripping from the air conditioner after use is normal. If you should notice any leaks or gasoline fumes are evident, check for the cause and correct it immediately. | |
The following tables show the normal maintenance schedule. Depending upon weather and atmospheric conditions, varying road surfaces, individual driving habits and vehicle usage, additional or more frequent maintenance may be required.
Periodic maintenance beyond the last period shown on the tables requires similar maintenance.
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 5 (8) 6 | 10 (16) 12 | 15 (24) 18 | 20 (32) 24 | 25 (40) 30 | 30 (48) 36 | 35 (56) 42 | 40 (64) 48 | 45 (72) 54 |
| Drive belt | (1) | | | | | | | | I (8) | |
| Air cleaner filter | (2) | | | | | | R | | | |
| EVAP vapor lines | | | | | I (8) | | | | I (8) | |
| Fuel lines | | | | | I (8) | | | | I (8) | |
| Fuel filter | (3) | | | | | | | | | |
| Engine coolant (8) | (4) (5) | | | | | | | | | |
| Engine oil | | R | R | R | R | R | R | R | R | R |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) | | R | R | R | R | R | R | R | R | R |
| Spark plugs (Iridium - tipped type) | (6) | Replace every 105, 000 miles (168, 000 km) |
| Intake and exhaust valve clearance (8) | (7) | | | | | | | | | |
| NOTE: (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (6) Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| NOTE |
|---|
| (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (6) Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. |
| (5) | Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. |
| (6) | Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. |
| (7) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (8) | Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
|---|
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 50 (80) 60 | 55 (88) 66 | 60 (96) 72 | 65 (104) 78 | 70 (112) 84 | 75 (120) 90 | 80 (128) 96 | 85 (136) 102 | 90 (144) 108 |
| Drive belt | (1) | I (8) | | I (8) | | I (8) | | I (8) | | I (8) |
| Air cleaner filter | (2) | | | R | | | | | | R |
| EVAP vapor lines | | | | I (8) | | | | I (8) | | |
| Fuel lines | | | | I (8) | | | | I (8) | | |
| Fuel filter | (3) | | | | | | | | | |
| Engine coolant (8) | (4) (5) | | | | | | | | | |
| Engine oil | | R | R | R | R | R | R | R | R | R |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) | | R | R | R | R | R | R | R | R | R |
| Spark plugs (Iridium - tipped type) | (6) | Replace every 105, 000 miles (168, 000 km) |
| Intake and exhaust valve clearance (8) | (7) | | | | | | | | | |
| NOTE: (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (6) Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| NOTE |
|---|
| (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (6) Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. |
| (5) | Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. |
| (6) | Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. |
| (7) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (8) | Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference |
|---|
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 95 (152) 114 | 100 (160) 120 | 105 (168) 126 | 110 (176) 132 | 115 (184) 138 | 120 (192) 144 |
| Drive belt | (1) | | I (8) | | I (8) | | I (8) | DRIVE BELT |
| Air cleaner filter | (2) | | | | | | R | AIR CLEANER FILTER |
| EVAP vapor lines | | | I (8) | | | | I (8) | EVAP VAPOR LINES |
| Fuel lines | | | I (8) | | | | I (8) | FUEL LINES |
| Fuel filter | (3) | | | | | | | |
| Engine coolant (8) | (4) (5) | | | | | | | ENGINE COOLANT |
| Engine oil | | R | R | R | R | R | R | ENGINE OIL |
| Engine oil filter (Use genuine NISSAN engine oil filter or equivalent) | | R | R | R | R | R | R | OIL FILTER |
| Spark plugs (Iridium - tipped type) | (6) | Replace every 105, 000 miles (168, 000 km) | SPARK PLUG |
| Intake and exhaust valve clearance (8) | (7) | | | | | | | BASIC INSPECTION |
| NOTE: (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (6) Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| NOTE |
|---|
| (1) After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. (2) If operating mainly in dusty conditions, more frequent maintenance may be required. (3) Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . (4) First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. (5) Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. (6) Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. (7) Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. (8) Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| (1) | After 40, 000 miles (64, 000 km) or 48 months, inspect every 10, 000 miles (16, 000 km) or 12 months. Replace the drive belts if found damaged. |
| (2) | If operating mainly in dusty conditions, more frequent maintenance may be required. |
| (3) | Maintenance-free item. For service procedures, refer to the FUEL SYSTEM . |
| (4) | First replacement interval is 105, 000 miles (168, 000 km) or 84 months. After first replacement, replace every 75, 000 miles (120, 000 km) or 60 months. |
| (5) | Use only Genuine NISSAN long life Antifreeze/Coolant (blue) or equivalent with proper mixture ratio of 50% anti-freeze and 50% demineralized or distilled water. Mixing any other type of coolant or the use of non-distilled water will reduce the life expectancy of the factory fill coolant. |
| (6) | Replace spark plug when the plug gap exceeds 1.35 mm (0.053 in) even if within specified periodic replacement mileage. |
| (7) | Periodic maintenance is not required. However, if valve noise increases, inspect valve clearance. |
| (8) | Maintenance items and intervals with "*" are recommended by INFINITI for reliable vehicle operation. The owner need not perform such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are required. |
| Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. |
|---|
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 5 (8) 6 | 10 (16) 12 | 15 (24) 18 | 20 (32) 24 | 25 (40) 30 | 30 (48) 36 | 35 (56) 42 | 40 (64) 48 | 45 (72) 54 |
| Brake lines & cables | | | I | | I | | I | | I | |
| Brake pads & rotors* | | | I | | I | | I | | I | |
| Brake fluid* | | | | | R | | | | R | |
| Automatic transmission fluid | (1) | | | | | | | | | |
| Transfer fluid & differential gear oil | (2) | | I | | I | | I | | I | |
| Steering gear & linkage, axle & suspension parts* | | | | | I | | | | I | |
| Tire rotation | (3) | | | | | | | | | |
| Propeller shaft & drive shaft boots (AWD models)* | | | I | | I | | I | | I | |
| Exhaust system* | | | | | I | | | | I | |
| In-cabin microfilter | | | | R | | | R | | | R |
| NOTE: Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (1) Automatic transmission fluid maintenance-free. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| NOTE |
|---|
| Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (1) Automatic transmission fluid maintenance-free. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| (1) | Automatic transmission fluid maintenance-free. |
| (2) | If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL |
|---|
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 50 (80) 60 | 55 (88) 66 | 60 (96) 72 | 65 (104) 78 | 70 (112) 84 | 75 (120) 90 | 80 (128) 96 | 85 (136) 102 | 90 (144) 108 |
| Brake lines & cables | | I | | I | | I | | I | | I |
| Brake pads & rotors* | | I | | I | | I | | I | | I |
| Brake fluid* | | | | R | | | | R | | |
| Automatic transmission fluid | (1) | | | | | | | | | |
| Transfer fluid & differential gear oil | (2) | I | | I | | I | | I | | I |
| Steering gear & linkage, axle & suspension parts* | | | | I | | | | I | | |
| Tire rotation | (3) | | | | | | | | | |
| Propeller shaft & drive shaft boots (AWD models)* | | I | | I | | I | | I | | I |
| Exhaust system* | | | | I | | | | I | | |
| In-cabin microfilter | | | | R | | | R | | | R |
| NOTE: Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (1) Automatic transmission fluid maintenance-free. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| NOTE |
|---|
| Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (1) Automatic transmission fluid maintenance-free. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| (1) | Automatic transmission fluid maintenance-free. |
| (2) | If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| MAINTENANCE OPERATION | MAINTENANCE INTERVAL | Reference |
|---|
| Perform at number of miles, kilometers or months, whichever comes first. | Miles x 1, 000 (km x 1, 000) Months | 95 (152) 114 | 100 (160) 120 | 105 (168) 126 | 110 (176) 132 | 115 (184) 138 | 120 (192) 144 |
| Brake lines & cables | | | I | | I | | I | BRAKE LINES AND CABLES |
| Brake pads & rotors* | | | I | | I | | I | DISC BRAKE |
| Brake fluid* | | | R | | | | R | BRAKE FLUID |
| Automatic transmission fluid | (1) | | | | | | | A/T FLUID |
| Transfer fluid & differential gear oil | (2) | | I | | I | | I | TRANSFER FLUID REAR PROPELLER SHAFT: 3F80A-1VL107 REAR DIFFERENTIAL GEAR OIL: R200 |
| Steering gear & linkage, axle & suspension parts* | | | I | | | | I | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS |
| Tire rotation | (3) | | | | | | | OUTSIDE THE VEHICLE WHEELS (BONDING WEIGHT TYPE) |
| Propeller shaft & drive shaft boots (AWD models)* | | | I | | I | | I | FRONT PROPELLER SHAFT: 2S56A REAR PROPELLER SHAFT: 3S80A-R REAR PROPELLER SHAFT: 3F80A-1VL107 DRIVE SHAFT |
| Exhaust system* | | | I | | | | I | EXHAUST SYSTEM |
| In-cabin microfilter | | | | R | | | R | PERIODIC MAINTENANCE |
| NOTE: Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (1) Automatic transmission fluid maintenance-free. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| NOTE |
|---|
| Maintenance items with "*" should be performed more frequently according to "Maintenance Under Severe Driving Conditions". (1) Automatic transmission fluid maintenance-free. (2) If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. (3) Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
| (1) | Automatic transmission fluid maintenance-free. |
| (2) | If towing a trailer, using a camper or car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 20, 000 miles (32, 000 km) or 24 months. |
| (3) | Refer to " TIRE ROTATION " under the "GENERAL MAINTENANCE" heading earlier in this article. |
The preceding maintenance intervals are for normal operating conditions. If the vehicle is mainly operated under severe driving conditions as shown below, more frequent maintenance must be performed on the following items as shown in the table.
Severe driving conditions
- Repeated short trips of less than 5 miles (8 km).
- Repeated short trips of less than 10 miles (16 km) with outside temperatures remaining below freezing.
- Operating in hot weather in stop-and-go "rush hour" traffic.
- Extensive idling and/or low speed driving for long distances, such as police, taxi or door-to-door delivery use.
- Driving in dusty conditions.
- Driving on rough, muddy, or salt spread roads.
- Towing a trailer, using a camper or a car-top carrier.
| Maintenance: operation: Inspect = Inspect and correct or replace as necessary. |
|---|
| Maintenance item | Maintenance operation | Maintenance interval | Reference |
| Brake fluid | Replace | Every 10, 000 km (16, 000 miles) or 12 months | BRAKE FLUID |
| Brake pads & rotors | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | DISC BRAKE |
| Steering gear & linkage, axle & suspension parts | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | STEERING GEAR AND LINKAGE AXLE AND SUSPENSION PARTS |
| Propeller shaft & drive shaft boots (AWD models) | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | FRONT PROPELLER SHAFT: 2S56A REAR PROPELLER SHAFT: 3S80A-R REAR PROPELLER SHAFT: 3F80A-1VL107 DRIVE SHAFT |
| Exhaust system | Inspect | Every 5, 000 miles (8, 000 km) or 6 months | EXHAUST SYSTEM |
Engine Oil Recommendation
NISSAN recommends the use of an energy conserving oil in order to improve fuel economy.
Select only engine oils that meet the American Petroleum Institute (API) certification and International Lubricant Standardization and Approval Committee (ILSAC) certification and SAE viscosity standard. These oils have the API certification mark on the front of the container. Oils which do not have the specified quality label should not be used as they could cause engine damage.
Scheme 40
Scheme 40: Engine Oil Recommendation
Anti-Freeze Coolant Mixture Ratio
The engine cooling system is filled at the factory with a pre-diluted mixture of 50% Genuine NISSAN Long Life Antifreeze/Coolant (blue) and 50% water to provide year-round anti-freeze and coolant protection. The antifreeze solution contains rust and corrosion inhibitors. Additional engine cooling system additives are not necessary.
| WARNING | Never remove the radiator or coolant reservoir cap when the engine is hot. Wait until the engine and radiator cool down. Serious burns could be caused by high pressure fluid escaping from the radiator. The radiator is equipped with a pressure type radiator cap. To prevent engine damage, use only a genuine NISSAN radiator cap. |
| CAUTION | When adding or replacing coolant, be sure to use only Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent. Genuine NISSAN Long Life Antifreeze/Coolant (blue) is pre-diluted to provide antifreeze protection to -34°F (-37°C). If additional freeze protection is needed due to weather where you operate your vehicle, add Genuine NISSAN Long Life Antifreeze/Coolant (blue) concentrate following the directions on the container. If an equivalent coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) is used, follow the coolant manufacture's instructions to maintain minimum antifreeze protection to -34°F (-37°C). The use of other types of coolant solutions other than Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent may damage the engine cooling system. Mixing any other type of coolant other than Genuine NISSAN Long Life Antifreeze/Coolant (blue), including Genuine NISSAN Long Life Antifreeze/Coolant (green), or the use of non-distilled water will reduce the life expectancy of the factory-fill coolant. |
Scheme 41
Scheme 41: DRIVE BELT: Exploded View
DRIVE BELT: Checking
| WARNING | Be sure to perform this step when engine is stopped. |
- Check that the indicator (C) (notch on fixed side) of drive belt auto-tensioner is within the possible use range (A). NOTE: Check the drive belt auto-tensioner indication when the engine is cold. When new drive belt is installed, the indicator (notch on fixed side) should be within the range (B) in the figure.
- Visually check entire drive belt for wear, damage or cracks.
- If the indicator (notch on fixed side) is out of the possible use range or belt is damaged, replace drive belt.
OIL LEAKAGE
Make sure that oil is not leaking from final drive assembly or around it.
Scheme 42
- Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure below. CAUTION: Never start engine while checking oil level.
- Set a gasket on filler plug and install it on final drive assembly. Refer to " «EXPLODED VIEW»(ref-617015-S23019399532014052000000) ". CAUTION: Never reuse gasket.
Scheme 43
Scheme 43: FRONT DIFFERENTIAL GEAR OIL: F160A: Draining
- Stop engine.
- Remove drain plug (1) and drain gear oil.
- Set a gasket on drain plug and install it to final drive assembly and tighten to the specified torque. Refer to " «EXPLODED VIEW»(ref-617015-S23019399532014052000000) ". CAUTION: Never reuse gasket.
- Make sure that oil is not leaking from final drive assembly or around it.
Scheme 44
- Remove filler plug (1) and check oil level from filler plug mounting hole as shown in the figure below. CAUTION: Never start engine while checking oil level.
- Set a gasket on filler plug and install it on final drive assembly. Refer to " «2WD: EXPLODED VIEW»(ref-617038-S12221943682014052000000) " (2WD), " «AWD: EXPLODED VIEW»(ref-617038-S32049023802014052000000) " (AWD). CAUTION: Never reuse gasket.
Scheme 45
Scheme 45: REAR DIFFERENTIAL GEAR OIL: R200: Draining
- Stop engine.
- Remove drain plug (1) and drain gear oil.
- Set a gasket on drain plug and install it to final drive assembly and tighten to the specified torque. Refer to " «2WD: EXPLODED VIEW»(ref-617038-S12221943682014052000000) " (2WD), " «AWD: EXPLODED VIEW»(ref-617038-S32049023802014052000000) " (AWD). CAUTION: Never reuse gasket.
BALANCING WHEELS (BONDING WEIGHT TYPE)
Preparation Before Adjustment
Using releasing agent, remove double-faced adhesive tape from the road wheel.
| CAUTION | Be careful not to scratch the road wheel during removal. After removing double-faced adhesive tape, wipe clean traces of releasing agent from the road wheel. |
If a tire balance machine has adhesion balance weight mode settings and drive-in weight mode setting, select and adjust a drive-in weight mode suitable for road wheels.
Scheme 46
Scheme 47
Scheme 48
- Set road wheel on tire balance machine using the center hole as a guide. Start the tire balance machine.
- When inner and outer unbalance values are shown on the tire balance machine indicator, multiply outer unbalance value by 5/3 to determine balance weight that should be used. Select the outer balance weight with a value closest to the calculated value above and install to the designated outer position of, or at the designated angle in relation to the road wheel. CAUTION: Do not install the inner balance weight before installing the outer balance weight. Before installing the balance weight, be sure to clean the mating surface of the road wheel. Indicated unbalance value x 5/3 = balance weight to be installed Calculation example: 23 g (0.81 oz) x 5/3 = 38.33 g (1.35 oz) --> 37.5 g (1.32 oz) balance weight (closer to calculated balance weight value) NOTE: Note that balance weight value must be closer to the calculated balance weight value. Example: 36.2 --> 35 g (1.23 oz) 36.3 --> 37.5 g (1.32 oz) Installed balance weight in the position. When installing balance weight (1) to road wheels, set it into the grooved area (A) on the inner wall of the road wheel as shown in the figure below, so that the balance weight center (B) is aligned with the tire balance machine indication position (angle) (C). CAUTION: Always use genuine NISSAN adhesion balance weights. Balance weights are non-reusable; always replace with new ones. Do not install more than three sheets of balance weight. If calculated balance weight value exceeds 50 g (1.76 oz), install two balance weight sheets in line with each other as shown in the figure below. CAUTION: Do not install one balance weight sheet on top of another.
- Start the tire balance machine again.
- Install drive-in balance weight on inner side of road wheel in the tire balance machine indication position (angle). CAUTION: Do not install more than two balance weight.
- Start the tire balance machine. Make sure that inner and outer residual unbalance values are 5 g (0.17 oz) each or below.
- If either residual unbalance value exceeds 5 g (0.17 oz), repeat installation procedures. Limit Dynamic (At flange): Refer to " «ROAD WHEEL»(ref-617041-S24443934192014052000000) ". Static (At flange): Refer to " «ROAD WHEEL»(ref-617041-S24443934192014052000000) ".
Scheme 49
- Follow the maintenance schedule for tire rotation service intervals. Refer to " «EXPLANATION OF GENERAL MAINTENANCE»(ref-617001-S03830809462014052000000) ".
- When installing the wheel, tighten wheel nuts to the specified torque. Refer to " «EXPLODED VIEW»(ref-617041-S36678465922014052000000) ". CAUTION: Do not include the T-type spare tire when rotating the tires. When installing wheels, tighten them diagonally by dividing the work two to three times in order to prevent the wheels from developing any distortion. Be careful not to tighten wheel nut at torque exceeding the criteria for preventing strain of disc rotor. Use NISSAN genuine wheel nuts for aluminum wheels.
- Perform the ID registration, after tire rotation. Refer to " «WORK PROCEDURE»(ref-617041-S19754284502014052000000) ".
Scheme 50
Scheme 50: BRAKE FLUID LEVEL AND LEAKS: Inspection
- If fluid level is extremely low, check brake system for leaks.
Scheme 51
Scheme 51: BRAKE LINES AND CABLES: Inspection
- Check brake fluid lines and parking brake cables for improper attachment, leaks, chafing, abrasions, deterioration, etc.
Scheme 52
Scheme 52: BRAKE FLUID: Changing
- Drain brake fluid from each bleed valve.
- Refill until new brake fluid comes out from each bleed valve. Use same procedure as in bleeding hydraulic system to refill brake fluid. Refer to " «BLEEDING BRAKE SYSTEM»(ref-617023-S37164690002014052000000) ". Refill with recommended Genuine NISSAN Super Heavy Duty Brake Fluid or equivalent DOT 3 (US FMVSS No. 116). Refer to " «FLUIDS AND LUBRICANTS»(ref-617001-S31558898562014052000000) ". Never reuse drained brake fluid. Be careful not to splash brake fluid on painted areas.
DISC ROTOR
Check condition, wear, and damage.
Scheme 53
Scheme 54
- Check for wear or damage.
DISC BRAKE: Front Disc Brake
| Unit: mm (in) |
|---|
| Item | Limit |
| Brake pad | Wear thickness | 2.0 (0.079) |
| Disc rotor | Wear thickness | 26.0 (1.024) |
| Thickness variation (measured at 8 positions) | 0.015 (0.0006) |
| Runout (with it attached to the vehicle) | 0.035 (0.0014) |
DISC BRAKE: Rear Disc Brake
| Unit: mm (in) |
|---|
| Item | Limit |
| Brake pad | Wear thickness | 2.0 (0.079) |
| Disc rotor | Wear thickness | 14.0 (0.551) |
| Thickness variation (measured at 8 positions) | 0.015 (0.0006) |
| Runout (with it attached to the vehicle) | 0.055 (0.0022) |
Scheme 55
- Check gear housing and boots for looseness, damage and grease leakage.
- Check connection with steering column for looseness.
STEERING LINKAGE
Check ball joint, dust cover and other component parts for looseness, wear, damage and grease leakage.
DRIVE BELT
| Tension of drive belt | Belt tension is not necessary, as it is automatically adjusted by drive belt auto-tensioner. |
SPARK PLUG
| Unit: mm (in) |
|---|
| Make | DENSO |
| Standard type | FXE22HR11 |
| Gap (Nominal) | 1.1 (0.043) |
ALUMINUM WHEEL (CONVENTIONAL)
| Item | Limit |
|---|
| Runout | Axial runout | Less than 0.3 mm (0.012 in) |
| Radial runout |
| Allowable unbalance | Dynamic (At flange) | Less than 5 g (0.17 oz) (one side) |
| Static (At flange) | Less than 10 g (0.35 oz) |
STEEL WHEEL (FOR EMERGENCY USE)
| Item | Limit |
|---|
| Runout | Axial runout (Average) | Less than 1.5 mm (0.059 in) |
| Radial runout (Average) |
