PHYSICAL VALUES Infiniti QX50 I

Mirrors 17 illustrations ~496 words

PHYSICAL VALUES

Terminal No. Wire color Description Condition Voltage (V) (Approx) + - Signal name Input/Output 1 Ground L/W UART communication (RX) Input Ignition switch ON 3 - R/Y CAN-H - - - 9 Ground W/G Reclining sensor signal Input Seat reclining Operate Stop 0 or 5 10 Ground P/B Lifting sensor (rear) signal Input Seat lifting (rear) Operate Stop 0 or 5 11 Ground BR Sliding switch backward signal Input Sliding switch Operate (backward) 0 Release Battery voltage 12 Ground SB Reclining switch backward signal Input Reclining switch Operate (backward) 0 Release Battery voltage 13 Ground LG/R Lifting switch (front) down signal Input Lifting switch (front) Operate (down) 0 Release Battery voltage 14 Ground G/B Lifting switch (rear) down signal Input Lifting switch (rear) Operate (down) 0 Release Battery voltage 16 Ground O Sensor power supply Output - 5 17 Ground Y/R UART communication (TX) Output Ignition switch ON 19 - V CAN-L - - - 21 Ground L/Y Detention switch Input A/T selector lever P position 0 Except P position 24 Ground R Sliding sensor signal Input Seat sliding Operate Stop 0 or 5 25 Ground Y/B Lifting sensor (front) signal Input Seat lifting (front) Operate Stop 0 or 5 26 Ground Y Sliding switch forward signal Input Sliding switch Operate (forward) 0 Release Battery voltage 27 Ground R/G Reclining switch forward signal Input Reclining switch Operate (forward) 0 Release Battery voltage 28 Ground W/B Lifting switch (front) up signal Input Seat lifting switch (front) Operate (up) 0 Release Battery voltage 29 Ground P/L Lifting switch (rear) up signal Input Seat lifting switch (rear) Operate (up) 0 Release Battery voltage 31 Ground GR Sensor ground - - 0 32 Ground B/W Ground (signal) - - 0 33 Ground R Power source (C/B) Input - Battery voltage 35 Ground W/R Sliding motor forward output signal Output Seat sliding Operate (forward) Battery voltage Release 0 36 Ground G/Y Reclining motor forward output signal Output Seat reclining Operate (forward) Battery voltage Release 0 37 Ground G/W Lifting motor (front) down output signal Output Seat lifting (front) Operate (down) Battery voltage Stop 0 38 Ground L/Y Lifting motor (rear) up output signal Output Seat lifting (rear) Operate (up) Battery voltage Stop 0 39 Ground R/B Lifting motor (rear) down output signal Output Seat lifting (rear) Operate (down) Battery voltage Stop 0 40 Ground R/W Power source (Fuse) Input - Battery voltage 42 Ground W/B Sliding motor backward output signal Output Seat sliding Operate (backward) Battery voltage Stop 0 44 Ground P Reclining motor backward output signal Output Seat reclining Operate (backward) Battery voltage Stop 0 45 Ground L/R Lifting motor (front) up output signal Output Seat lifting (front) Operate (up) Battery voltage Stop 0 48 Ground B Ground (power) - - 0

Scheme 24

Scheme 24: PHYSICAL VALUES

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27: Wiring Diagram - AUTOMATIC DRIVE POSITIONER CONTROL SYSTEM

Scheme 28

Scheme 28

Scheme 29

Scheme 29

Scheme 30

Scheme 30

Scheme 31

Scheme 31

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35

Scheme 36

Scheme 36

Scheme 37

Scheme 37

Scheme 38

Scheme 38

Scheme 39

Scheme 39

Scheme 40

Scheme 40
