Adjustment
Adjust the guide line position if the guide line position is shifted after installing the rear view camera.
Scheme 4
- Draw lines on rearward area of the vehicle passing through the following points: 200 mm (7.87 in) from both sides of the vehicle, and 0.5 m (1.64 ft), 1.0 m (3.28 ft) from the rear end of the bumper.
- Set into "Adjust Guide Lines" mode of "Confirmation/Adjustment" mode.
- Rotate the center dial, and then select the guiding line pattern so that its angle is aligned with the correction line of the rear of the vehicle. Selected pattern: 7
- Make fine adjustment to the correction line of the rear of the vehicle with up/down/left/right switches so that its position is aligned with the guiding line. Press "OK" switch and record the adjusted guiding line position to the AV control unit. Up/Down adjustment range: 20° to 20° Left/Right adjustment range: 20° to 20° CAUTION: After the adjustment, never perform other operations for one minute.
