Driver Assistance System (Dca): Removal & Installation Infiniti QX50 I

Collision/avoidance 2 illustrations ~132 words

REMOVAL

  1. Remove front bumper fascia. Refer to " «EXPLODED VIEW»(ref-617007-S07099924242014052000000) ".
  2. Disconnect ICC sensor integrated unit connector.
  3. Remove mounting bolts from ICC sensor integrated unit.
  4. Remove ICC sensor integrated unit.

INSTALLATION

Install in the reverse order of removal.

CAUTIONAlways perform the laser beam aiming adjustment and check the operation after the replacement, removal, and installation of ICC sensor integrated unit. Refer to " ADDITIONAL SERVICE WHEN REPLACING CONTROL UNIT (ICC SENSOR INTEGRATED UNIT): DESCRIPTION ".

Scheme 89

Scheme 89: Exploded View
Scheme 89: Exploded View
  1. Remove clips on the back of the luggage side finisher lower (RH) to obtain space for work. Refer to " «REMOVAL AND INSTALLATION»(ref-617008-S18176850452014052000000) ".
  2. Disconnect brake booster control unit connector.
  3. Remove mounting bolts from brake booster control unit.
  4. Remove brake booster control unit.

Install in the reverse order of removal.

Scheme 90

Scheme 90: Exploded View
Scheme 90: Exploded View
  1. Remove the combination meter. Refer to " «EXPLODED VIEW»(ref-617020-S18829917862014052000000) ".
  2. Disconnect ICC warning chime connector.
  3. Remove mounting screw from ICC warning chime.
  4. Remove ICC warning chime.

Install in the reverse order of removal.
