Torque Converter
Check torque converter one-way clutch using a check tool as shown in the figure below.
Scheme 1
- Insert a check tool into the groove of bearing support built into one-way clutch outer race.
- When fixing bearing support with a check tool, rotate one-way clutch spline using a screwdriver.
- Make sure that inner race rotates clockwise only. If not, replace torque converter assembly.
General Specification
| Applied model | VQ37VHR | ||
|---|---|---|---|
| 2WD | AWD | ||
| Transmission model code number | X976A | X976B | |
| Stall torque ratio | 1.92: 1 | ||
| Transmission gear ratio | 1st | 4.924 | |
| 2nd | 3.194 | ||
| 3rd | 2.043 | ||
| 4th | 1.412 | ||
| 5th | 1.000 | ||
| 6th | 0.862 | ||
| 7th | 0.772 | ||
| Reverse | 3.972 | ||
| Recommended fluid and fluid capacity | Refer to " RECOMMENDED FLUIDS AND LUBRICANTS ". | ||
| Dimension between end of converter housing and torque converter | 25.0 mm (0.98 in) |
