PHYSICAL VALUES Infiniti Q60 I

Power Window Control System (Coupe) 39 illustrations ~2277 words

PHYSICAL VALUES

Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (W) Ground Battery power supply Input Ignition switch OFF Battery voltage 2 (Y) Ground P/W power supply (BAT) Output Ignition switch OFF 12 V 3 (BG) Ground P/W power supply (RAP) Output Ignition switch ON 12 V 4 (LG) Ground Interior room lamp power supply Output Interior room lamp battery saver is activated. (Cuts the interior room lamp power supply) 0 V Interior room lamp battery saver is not activated. (Outputs the interior room lamp power supply) 12 V 5 (P) Ground Passenger door UNLOCK Output Passenger door UNLOCK (Actuator is activated) 12 V Other than UNLOCK (Actuator is not activated) 0 V 7 (SB) Ground Step lamp Output Step lamp ON 0 V OFF 12 V 8 (V) Ground All doors, fuel lid LOCK Output All doors, fuel lid LOCK (Actuator is activated) 12 V Other than LOCK (Actuator is not activated) 0 V 9 (G) Ground Driver door, fuel lid UNLOCK Output Driver door, fuel lid UNLOCK (Actuator is activated) 12 V Other than UNLOCK (Actuator is not activated) 0 V 11 (R) Ground Battery power supply Input Ignition switch OFF Battery voltage 13 (B) Ground Ground - Ignition switch ON 0 V 14 (W) Ground Push-button ignition switch illumination ground Output Tail lamp OFF 0 V ON NOTE: When the illumination brightening/dimming level is in the neutral position. 15 (BG) Ground ACC indicator lamp Output Ignition switch OFF (LOCK indicator is not illuminated) Battery voltage ACC 0 V 17 (W) Ground Turn signal RH (Front) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 18 (BG) Ground Turn signal LH (Front) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 19 (V) Ground Interior room lamp control Output Interior room lamp OFF 12 V ON 0 V 20 (V) Ground Turn signal RH (Rear) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 23 (LG) Ground Trunk lid open Output Trunk lid OPEN (Trunk lid opener actuator is activated) 12 V Other than OPEN (Trunk lid opener actuator is not activated) 0 V 25 (Y) Ground Turn signal LH (Rear) Output Ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 30 (P) Ground Trunk room lamp Output Trunk room lamp ON 0 V OFF 12 V 34 (SB) Ground Trunk room antenna (-) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 35 (V) Ground Trunk room antenna (+) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 38 (B) Ground Rear bumper antenna (-) Output When the trunk lid opener request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 39 (W) Ground Rear bumper antenna (+) Output When the trunk lid opener request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 47 (Y) Ground Ignition relay (IPDM E/R) control Output Ignition switch OFF or ACC 12 V ON 0 V 50 (BG) Ground Trunk room lamp switch Input Trunk room lamp switch OFF (Trunk lid is closed) ON (Trunk lid is opened) 0 V 52 (R) Ground Starter relay control Output Ignition switch ON (A/T models) When selector lever is in P or N position 12 V When selector lever is not in P or N position 0 V Ignition switch ON (M/T models) When the clutch pedal is depressed Battery voltage When the clutch pedal is not depressed 0 V 60 (BR) Ground Push-button ignition switch (Push switch) Input Push-button ignition switch (Push switch) Pressed 0 V Not pressed Battery voltage 61 (SB) Ground Trunk lid opener request switch Input Trunk lid opener request switch ON (Pressed) 0 V OFF (Not pressed) 64 (G) Ground Intelligent Key warning buzzer (Engine room) Output Intelligent Key warning buzzer (Engine room) Sounding 0 V Not sounding 12 V 67 (GR) Ground Trunk lid opener switch Input Trunk lid opener switch Pressed 0 V Not pressed 72 (R) Ground Room antenna 2 (-) (Center console) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 73 (G) Ground Room antenna 2 (+) (Center console) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 74 (SB) Ground Passenger door antenna (-) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 75 (BR) Ground Passenger door antenna (+) Output When the passenger door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 76 (V) Ground Driver door antenna (-) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 77 (LG) Ground Driver door antenna (+) Output When the driver door request switch is operated with ignition switch OFF When Intelligent Key is in the antenna detection area When Intelligent Key is not in the antenna detection area 78 (Y) Ground Room antenna 1 (-) (Instrument panel) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 79 (BR) Ground Room antenna 1 (+) (Instrument panel) Output Ignition switch OFF When Intelligent Key is in the passenger compartment When Intelligent Key is not in the passenger compartment 80 (GR) Ground NATS antenna amp. Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 81 (W) Ground NATS antenna amp. Input/Output During waiting Ignition switch is pressed while inserting the Intelligent Key into the key slot. Just after pressing ignition switch. Pointer of tester should move. 82 (SB) Ground Ignition relay [Fuse block (J/B)] control Output Ignition switch OFF or ACC 0 V ON 12 V 83 (Y) Ground Remote keyless entry receiver communication Input/Output During waiting When operating either button on the Intelligent Key 87 (Y) Ground Combination switch INPUT 5 Input Combination switch All switches OFF (Wiper volume dial 4) Front fog lamp switch ON (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 2 Wiper volume dial 6 Wiper volume dial 7 88 (BG) Ground Combination switch INPUT 3 Input Combination switch All switches OFF (Wiper volume dial 4) Lighting switch HI (Wiper volume dial 4) Lighting switch 2ND (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 2 Wiper volume dial 3 90 (P) Ground CAN-L Input/Output - - 91 (L) Ground CAN-H Input/Output - - 92 (LG) Ground Key slot illumination Output Key slot illumination OFF 12 V Blinking ON 0 V 93 (GR) Ground ON indicator lamp Output Ignition switch OFF (LOCK indicator is not illuminated) Battery voltage ON 0 V 95 (BG) Ground ACC relay control Output Ignition switch OFF 0 V ACC or ON 12 V 96 (GR) Ground A/T shift selector (Detention switch) power supply Output - 12 V 99 (R) (1) (BR) (2) Ground Selector lever P position switch (A/T models) Input Selector lever P position 0 V Any position other than P 12 V ASCD clutch switch (M/T models) ASCD clutch switch OFF (Clutch pedal is depressed) 0 V ON (Clutch pedal is not depressed) 12 V 100 (Y) Ground Passenger door request switch Input Passenger door request switch ON (Pressed) 0 V OFF (Not pressed) 101 (P) Ground Driver door request switch Input Driver door request switch ON (Pressed) 0 V OFF (Not pressed) 102 (BG) Ground Blower fan motor relay control Output Ignition switch OFF or ACC 0 V ON 12 V 103 (P) Ground Remote keyless entry receiver power supply Output Ignition switch OFF 12 V 107 (LG) Ground Combination switch INPUT 1 Input Combination switch (Wiper volume dial 4) All switches OFF Turn signal switch LH Turn signal switch RH Front wiper switch LO Front washer switch ON 108 (R) Ground Combination switch INPUT 4 Input Combination switch All switches OFF (Wiper volume dial 4) Lighting switch AUTO (Wiper volume dial 4) Lighting switch 1ST (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 5 Wiper volume dial 6 109 (W) Ground Combination switch INPUT 2 Input Combination switch (Wiper volume dial 4) All switches OFF Lighting switch PASS Lighting switch 2ND Front wiper switch INT/AUTO Front wiper switch HI 110 (G) Ground Hazard switch Input Hazard switch ON 0 V OFF 112 (R) Ground Rain sensor serial link Input/Output Ignition switch ON 113 (BG) Ground Optical sensor Input Ignition switch ON When bright outside of the vehicle Close to 5 V When dark outside of the vehicle Close to 0 V 114 (R) Ground Clutch interlock switch Input Clutch interlock switch OFF (Clutch pedal is not depressed) 0 V ON (Clutch pedal is depressed) Battery voltage 116 (SB) Ground Stop lamp switch 1 Input - Battery voltage 118 (BR) Ground Stop lamp switch 2 (Without ICC) Input Stop lamp switch OFF (Brake pedal is not depressed) 0 V ON (Brake pedal is depressed) Battery voltage Stop lamp switch 2 (With ICC) Stop lamp switch OFF (Brake pedal is not depressed) and ICC brake hold relay OFF 0 V Stop lamp switch ON (Brake pedal is depressed) or ICC brake hold relay ON Battery voltage 119 (SB) Ground Driver side door lock assembly (Unlock sensor) Input Driver door LOCK status (Unlock sensor switch OFF) UNLOCK status (Unlock switch sensor ON) 0 V 121 (SB) Ground Key slot switch Input When the Intelligent Key is inserted into key slot 12 V When the Intelligent Key is not inserted into key slot 0 V 123 (V) Ground IGN feedback Input Ignition switch OFF or ACC 0 V ON Battery voltage 124 (R) Ground Passenger door switch Input Passenger door switch OFF (Door close) ON (Door open) 0 V 129 (BG) Ground Trunk lid opener cancel switch Input Trunk lid opener cancel switch CANCEL ON 0 V 132 (V) Ground Power window switch communication Input/Output Ignition switch ON Ignition switch OFF or ACC 12 V 133 (L) Ground Push-button ignition switch illumination Output Push-button ignition switch illumination ON (Tail lamps OFF) 9.5 V ON (Tail lamps ON) NOTE: The pulse width of this wave is varied by the illumination brightening/dimming level. OFF 0 V 134 (LG) Ground LOCK indicator lamp Output LOCK indicator lamp OFF Battery voltage ON 0 V 137 (BG) Ground Receiver and sensor ground Input Ignition switch ON 0 V 138 (V) Ground Receiver and sensor power supply Output Ignition switch OFF 0 V ACC or ON 5.0 V 139 (L) Ground Tire pressure receiver communication Input/Output Ignition switch ON Standby state When receiving the signal from the transmitter 140 (1) (B) Ground Selector lever P/N position Input Selector lever P or N position 12 V Except P and N positions 0 V 141 (W) Ground Security indicator lamp Output Security indicator lamp ON 0 V Blinking OFF 12 V 142 (BR) Ground Combination switch OUTPUT 5 Output Combination switch (Wiper volume dial 4) All switches OFF 0 V Lighting switch 1ST Lighting switch HI Lighting switch 2ND Turn signal switch RH 143 (P) Ground Combination switch OUTPUT 1 Output Combination switch All switches OFF (Wiper volume dial 4) 0 V Front wiper switch HI (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 2 Wiper volume dial 3 Wiper volume dial 6 Wiper volume dial 7 144 (G) Ground Combination switch OUTPUT 2 Output Combination switch All switches OFF (Wiper volume dial 4) 0 V Front washer switch ON (Wiper volume dial 4) Any of the conditions below with all switches OFF Wiper volume dial 1 Wiper volume dial 5 Wiper volume dial 6 145 (L) Ground Combination switch OUTPUT 3 Output Combination switch (Wiper volume dial 4) All switches OFF 0 V Front wiper switch INT/AUTO Front wiper switch LO Lighting switch AUTO 146 (SB) Ground Combination switch OUTPUT 4 Output Combination switch (Wiper volume dial 4) All switches OFF 0 V Front fog lamp switch ON Lighting switch 2ND Lighting switch PASS Turn signal switch LH 150 (GR) Ground Driver door switch Input Driver door switch OFF (Door close) ON (Door open) 0 V 151 (G) Ground Rear window defogger relay control Output Rear window defogger Active 0 V Not activated Battery voltage (1) A/T models (2) M/T models
