Component Function Check Infiniti Q60 I

Exterior Lighting System (Coupe) 3 illustrations ~1604 words

Component Function Check

  1. CHECK HEADLAMP (HI) OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the headlamp switches to the high beam. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the test items, check that the headlamp switches to the high beam. Hi: Headlamp switches to the high beam. Off: Headlamp OFF NOTE: HI/LO is repeated 1 second each when using the IPDM E/R auto active test. Does the headlamp switch to the high beam? YES: Headlamp (HI) circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S28407471042014100600000) ".
  1. CHECK HEADLAMP (LO) OPERATION IPDM E/R AUTO ACTIVE TEST Start IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the headlamp is turned ON. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the test items, check that the headlamp is turned ON. Lo: Headlamp ON Off: Headlamp OFF Is the headlamp turned ON? YES: Headlamp (LO) is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S41625823262014100600000) ".
  1. The lamp light source is by the arch discharge by applying high voltage into the xenon gas-filled bulb instead of the halogen bulb filament.
  2. Sight becomes more natural and brighter because the amount of light are gained adequately and the color of light is sunshine-like white.
  3. The xenon bulb drops the amount of light, repeats blinking, and illuminates in red if the bulb reaches the service life.

Scheme 208

Scheme 208: ILLUMINATION PRINCIPLE
Scheme 208: ILLUMINATION PRINCIPLE
  1. Discharging starts in high voltage pulse between bulb electrodes.
  2. Xenon gas is activated by current between electrodes. Pale light is emitted.
  3. The luminous tube (bulb) temperature elevates. Evaporated halide is activated by discharge. The color of light changes into white. NOTE: Brightness and the color of light may change slightly immediately after the headlamp turned ON until the xenon bulb becomes stable. This is not malfunction. Illumination time lag may occur between right and left. This is not malfunction.
  1. CHECK DAYTIME RUNNING LIGHT OPERATION IPDM E/R AUTO ACTIVE TEST Activate IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the parking lamp and tail lamp are turned ON. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the test item, check that parking lamp and tail lamp are turned ON. TAIL: Parking lamp and tail lamp ON Off: Parking lamp and tail lamp OFF Are parking lamp and tail lamp turned ON? YES: Daytime running light relay circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S08456294282014100600000) ".
  1. CHECK FRONT FOG LAMP OPERATION IPDM E/R AUTO ACTIVE TEST Activate IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the front fog lamp is turned ON. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the test items, Check that the front fog lamp is turned ON. Fog: Front fog lamp ON Off: Front fog lamp OFF Is the front fog lamp turned ON? YES: Front fog lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S15427834782014100600000) ".
  1. CHECK PARKING LAMP OPERATION IPDM E/R AUTO ACTIVE TEST Activate IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the parking lamp is turned ON. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the test items, check that the parking lamp is turned ON. TAIL: Parking lamp ON Off: Parking lamp OFF Is the parking lamp turned ON? YES: Parking lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S39132148662014100600000) ".
  1. CHECK TURN SIGNAL LAMP CONSULT ACTIVE TEST Select "FLASHER" of BCM (FLASHER) active test item. With operating the test items, check that the turn signal lamp blinks. LH: Turn signal lamp LH blinking RH: Turn signal lamp RH blinking Off: The turn signal lamp OFF Does the turn signal lamp blink? YES: Turn signal lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S05563816212014100600000) ".

Scheme 209

Scheme 209: Diagnosis Procedure
Scheme 209: Diagnosis Procedure
  1. CHECK TURN SIGNAL LAMP BULB Check the applicable lamp bulb. Is the bulb normal? YES: GO TO 2. NO: Replace the bulb.
  2. CHECK TURN SIGNAL LAMP OUTPUT VOLTAGE CONSULT ACTIVE TEST Turn the ignition switch OFF. Disconnect the front combination lamp connector or the rear combination lamp connector. Turn the ignition switch ON. Select "FLASHER" of BCM (FLASHER) active test item. With operating the turn signal switch, check the voltage between the BCM harness connector and the ground. VOLTAGE REFERENCE (FRONT) Terminals Test item Voltage (Approx.) (+) (-) BCM Ground FLASHER Connector Terminal RH M119 17 RH Off 0 V LH 18 LH Off 0 V VOLTAGE REFERENCE (REAR) Terminals Test item Voltage (Approx.) (+) (-) BCM Ground FLASHER Connector Terminal RH M120 20 RH Off 0 V LH 25 LH Off 0 V Is the measurement value normal? YES: GO TO 3. NO: Replace BCM.
  3. CHECK TURN SIGNAL LAMP OPEN CIRCUIT Turn the ignition switch OFF. Disconnect BCM connector. Check the continuity between the BCM harness connector and the front combination lamp or the rear combination lamp harness connector. FRONT COMBINATION LAMP CONTINUITY REFERENCE BCM Front combination lamp Continuity Connector Terminal Connector Terminal RH M119 17 E28 6 Existed LH 18 E58 6 REAR COMBINATION LAMP CONTINUITY REFERENCE BCM Rear combination lamp Continuity Connector Terminal Connector Terminal RH M120 20 B67 4 Existed LH 25 B60 4 Does continuity exist? YES: GO TO 4. NO: Repair the harnesses or connectors.
  4. CHECK TURN SIGNAL LAMP SHORT CIRCUIT Check continuity between the BCM harness connector and the ground. CONTINUITY REFERENCE (FRONT) BCM Ground Continuity Connector Terminal RH M119 17 Not existed LH 18 CONTINUITY REFERENCE (REAR) BCM Ground Continuity Connector Terminal RH M120 20 Not existed LH 25 Does continuity exist? YES: Repair the harnesses or connectors. NO: GO TO 5.
  5. CHECK TURN SIGNAL LAMP GROUND OPEN CIRCUIT Check the voltage between the BCM harness connector and the front combination lamp or the rear combination lamp and the ground. FRONT COMBINATION LAMP CONTINUITY REFERENCE Front combination lamp Ground Continuity Connector Terminal RH E28 4 Existed LH E58 4 REAR COMBINATION LAMP CONTINUITY REFERENCE Rear combination lamp Ground Continuity Connector Terminal RH B67 3 Existed LH B60 3 Does continuity exist? YES: Replace the front combination lamp or the rear combination lamp. NO: Repair the harnesses or connectors.
  1. CHECK OPTICAL SENSOR SIGNAL BY CONSULT CONSULT DATA MONITOR Turn the ignition switch ON. Select "OPTICAL SENSOR" of BCM (HEADLAMP) data monitor item. Turn the lighting switch AUTO. With the optical sensor illuminating, check the monitor status. Monitor item Condition Voltage (Approx.) OPTICAL SENSOR Optical sensor When illuminating 3.1 V or more (1) When shutting off light 0.6 V or less (1) Illuminates the optical sensor. The value may be less than the standard value if brightness is weak. Is the item status normal? YES: Optical sensor is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S04824323502014100600000) ".
  1. CHECK HAZARD SWITCH SIGNAL BY CONSULT CONSULT DATA MONITOR Turn the ignition switch ON. Select "HAZARD SW" of BCM (FLASHER) data monitor item. With operating the hazard switch, check the monitor status. Monitor item Condition Monitor status HAZARD SW Hazard switch While pressing the switch On While not pressing the switch Off Is the item status normal? YES: Hazard switch circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S39824634762014100600000) ".

Scheme 210

Scheme 210: Diagnosis Procedure
Scheme 210: Diagnosis Procedure
  1. CHECK HAZARD SWITCH SIGNAL INPUT With operating the hazard switch, check the voltage between the BCM harness connector and the ground. Terminals Condition Voltage (Approx.) (+) (-) BCM Ground Hazard switch Connector Terminal M122 110 While pressing the switch 0 V While not pressing the switch Is the measurement value normal? YES: Replace BCM. NO: GO TO 2.
  2. CHECK HAZARD SWITCH SIGNAL OPEN CIRCUIT Turn the ignition switch OFF. Disconnect the multifunction switch connector and BCM connector. Check continuity between the multifunction switch harness connector and the BCM harness connector. Multifunction switch BCM Continuity Connector Terminal Connector Terminal M72 16 M122 110 Existed Does continuity exist? YES: GO TO 3. NO: Repair the harnesses or connectors.
  3. CHECK HAZARD SWITCH SIGNAL SHORT CIRCUIT Check continuity between the multifunction switch harness connector and the ground. Multifunction switch Ground Continuity Connector Terminal M72 16 Not existed Does continuity exist? YES: Repair the harnesses or connectors. NO: GO TO 4.
  4. CHECK HAZARD SWITCH GROUND OPEN CIRCUIT Check continuity between the multifunction switch harness connector and the ground. Multifunction switch Ground Continuity Connector Terminal M72 1 Existed Does continuity exist? YES: Replace the hazard switch (multifunction switch). NO: Repair the harnesses or connectors.
  1. CHECK TAIL LAMP OPERATION IPDM E/R AUTO ACTIVE TEST Activate IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the tail lamp is turned ON. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the test items, check that the tail lamp is turned ON. TAIL: Tail lamp ON Off: Tail lamp OFF Is the tail lamp turned ON? YES: Tail lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S38836034452014100600000) ".

Note. Check the tail lamp circuit if the tail lamp and the license plate lamp are not turned ON.

  1. CHECK LICENSE PLATE LAMP OPERATION IPDM E/R AUTO ACTIVE TEST Activate IPDM E/R auto active test. Refer to " «DIAGNOSIS DESCRIPTION»(ref-660632-S11680361032014100600000) ". Check that the license plate lamp is turned ON. CONSULT ACTIVE TEST Select "EXTERNAL LAMPS" of IPDM E/R active test item. With operating the lighting switch, check that the license plate lamp is turned ON. TAIL: License plate lamp ON Off: License plate lamp OFF Is the license plate lamp turned ON? YES: License plate lamp circuit is normal. NO: Refer to " «DIAGNOSIS PROCEDURE»(ref-660641-S26660236462014100600000) ".
