Exploded View Infiniti Q60 I

Door & Lock (Convertible) 6 illustrations ~361 words

Exploded View

Refer to " EXPLODED VIEW ".

Scheme 185

Scheme 185: REMOVAL
Scheme 185: REMOVAL
  1. Remove the rear bumper. Refer to " «REMOVAL AND INSTALLATION»(ref-659749-S23045920312014100100000) ".
  2. Remove the outside key antenna (rear bumper) mounting nuts (A), and then remove outside key antenna (rear bumper) (1).

Refer to " EXPLODED VIEW ".

Scheme 186

Scheme 186: REMOVAL
Scheme 186: REMOVAL
  1. Remove the hood seal assembly (side). Refer to " «REMOVAL AND INSTALLATION»(ref-659757-S21946955362014100100000) ".
  2. Remove the Intelligent Key warning buzzer mounting bolt (A), and then remove the Intelligent Key warning buzzer (1).

Refer to " EXPLODED VIEW ".

Scheme 187

Scheme 187: REMOVAL
Scheme 187: REMOVAL
  1. Remove the rear combination lamp LH (1). Refer to " «REMOVAL AND INSTALLATION»(ref-659769-S24396305622014100100000) ".
  2. Remove the trunk lid opener request switch connector (B).
  3. Remove the trunk lid opener request switch mounting screw (A), and then remove trunk lid opener request switch (2) from rear combination lamp LH.

Refer to " A/T MODELS: EXPLODED VIEW " (A/T models) or " M/T MODELS: EXPLODED VIEW " (M/T models).

Scheme 188

Scheme 188: REMOVAL
Scheme 188: REMOVAL
  1. Remove the instrument driver lower panel. Refer to " «A/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S25653261642014100100000) " (A/T models) or " «M/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S24721773792014100100000) " (M/T models).
  2. Remove the trunk lid opener switch (1) from instrument driver lower panel, and then remove pawl (A). Press trunk lid opener switch front side to disengage from instrument driver lower panel.

Refer to " A/T MODELS: EXPLODED VIEW " (A/T models) or " M/T MODELS: EXPLODED VIEW " (M/T models).

Scheme 189

Scheme 189: REMOVAL
Scheme 189: REMOVAL
  1. Remove the instrument assist lower panel. Refer to " «A/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S31915970622014100100000) " (A/T models) or " «M/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S24721773792014100100000) " (M/T models).
  2. Remove the trunk lid opener cancel switch (1) from instrument assist lower panel, and then remove pawl (A). Press trunk lid opener cancel switch back side to disengage from instrument assist lower panel.

Refer to " A/T MODELS: EXPLODED VIEW " (A/T models) or " M/T MODELS: EXPLODED VIEW " (M/T models).

Scheme 190

Scheme 190: REMOVAL
Scheme 190: REMOVAL
  1. Remove the instrument assist lower panel. Refer to " «A/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S31915970622014100100000) " (A/T models) or " «M/T MODELS: REMOVAL AND INSTALLATION»(ref-659773-S24721773792014100100000) " (M/T models).
  2. Remove the remote keyless entry receiver mounting bolt (A), and then remove remote keyless entry receiver (1).
